Запчасти Komatsu JV40CW-3 МАРКИРОВКА (АНГЛ.)(№-) МАРКИРОВКА И ИНСТРУМЕНТ

1

09653-03010

PLATE, SAFETY,HYDRAULIC OIL

SN: 5001-UP

1шт.

2

09652-30121

PLATE, CAUTION,FUEL

SN: 5001-UP

1шт.

3

09994-00205

PLATE, SAFETY,ANTIFREEZING SOLUTION

SN: 5001-UP

1шт.

4

2691-9-19210

PLATE, MARK,WATER

SN: 5001-UP

1шт.

5

09669-00001

PLATE, CAUTION,COOLANT

SN: 5001-UP

1шт.

6

266-90-44520

PLATE, SAFETY,RADIATOR

SN: 5001-UP

1шт.

7

258-06-92529

PLATE, OPERATING,VIBRATION STOP

SN: 5001-UP

1шт.

8

258-59-21171

MARK,JV40CW

SN: 5001-UP

1шт.

9

258-06-90180

PLATE, MARK,JV

SN: 5001-UP

1шт.

10

258-06-92532

PLATE, MARK,WATER DRAIN

SN: 5497-UP

1шт.

10

258-06-92531

PLATE, MARK,WATER DRAIN

SN: 5001-5496

1шт.

11

265-90-12243

REFLECTOR

SN: 5001-UP

2шт.

12

258-06-90054

PLATE, MARK,KOMATSU

SN: 5001-UP

1шт.

13

258-06-90062

PLATE, MARK,HOWA

SN: 5001-UP

1шт.

14

258-06-90054

PLATE, MARK,KOMATSU

SN: 5001-UP

1шт.

15

258-06-90180

PLATE, MARK,JV

SN: 5001-UP

1шт.

16

258-59-21171

MARK,JV40CW

SN: 5001-UP

1шт.

17

26991-11721

PLATE, MARK,MACHINE NO.

SN: 5001-UP

1шт.

17

266-80-13360

SCREW

SN: 5001-UP

4шт.

18

258-90-41230

PLATE, CAUTION,BYPASS VALVE

SN: 5497-UP

1шт.

18

268-85-14810

PLATE, CAUTION,BYPASS VALVE

SN: 5001-5496

1шт.

19

258-06-90043

PLATE, MARK,BRAKE RELEASE

SN: 5001-UP

1шт.

20

2692-9-11170

PLATE, NAME,MAKER'S

SN: 5001-UP

1шт.

20

266-80-13360

SCREW

SN: 5001-UP

4шт.

21

258-06-92024

PLATE, MARK,HIGH-LOW CONTROL LEVER

SN: 5001-UP

1шт.

22

266-90-43380

PLATE, OPERATING,STARTING SWITCH

SN: 5001-UP

1шт.

23

258-06-91583

PLATE, MARK,SPEC.

SN: 5001-UP

1шт.

24

258-06-93502

PLATE, CAUTION,STEERING HOSE

SN: 5001-UP

1шт.

25

266-90-93503

PLATE, SAFETY,WARNING

SN: 5001-UP

1шт.

26

2692-9-11330

PLATE, SAFETY,CAUTION

SN: 5001-UP

1шт.

27

258-06-90026

PLATE, MARK,OIL SPRAY

SN: 5301-UP

1шт.

28

259-90-41210

PLATE, OPERATING,VIBRATION AND WATER SPRAY

SN: 5301-UP

1шт.

29

258-90-21261

PLATE, MARK,WORK LAMP

SN: 5001-UP

1шт.

30

258-90-21281

PLATE, MARK,CAUTION LAMP

SN: 5001-UP

1шт.

31

258-90-21273

PLATE, MARK,PARKING BRAKE

SN: 5001-UP

1шт.

32

258-06-90007

PLATE, MARK,FORWARD, REVERSE, NEUTRAL

SN: 5001-UP

2шт.

33

258-06-90005

PLATE, MARK,TURN SIGNAL

SN: 5001-UP

1шт.

34

258-90-11110

PLATE, MARK,FUEL LEVER

SN: 5001-UP

1шт.

35

258-06-90396

PLATE, CAUTION

SN: 5301-UP

2шт.

36

258-06-90393

PLATE, MARK,HOOK

SN: 5301-UP

4шт.

37

258-06-90397

PLATE, CAUTION,WARNING

SN: 5301-UP

2шт.

38

258-09-90398

PLATE, CAUTION,WARNING

SN: 5301-UP

1шт.
