Запчасти Komatsu JV100A-2T ГИДРАВЛИКА РУЛ. УПРАВЛЕНИЯ (/) (БАК - КЛАПАН РУЛЕВОГО УПРАВЛЕНИЯ) СИЛОВАЯ ПЕРЕДАЧА
№
Артикул
Название
Примечание
Количество
10
FUEL CONTROL LINKAGE (FOR WRIST CONTROL LEVER)
SN: 11001-UP
1шт.
20
CONTROL PEDAL AND LINKAGE (FOR ATTACHMENT)(#1001-1199)
SN: 11001-UP
1шт.
30
CONTROL PEDAL AND LINKAGE (FOR ATTACHMENT)(#1200-)
SN: 11001-UP
1шт.
40
TRAVEL CONTROL LINKAGE(#1001-1199)
SN: 11001-UP
1шт.
50
TRAVEL CONTROL LINKAGE(#1200-1403)
SN: 11001-UP
1шт.
60
TRAVEL CONTROL LINKAGE(#1404-)
SN: 11001-UP
1шт.
70
TRAVEL CONTROL LINKAGE (WITH TRAVEL LOCK) (FOR WRIST CONTROL LEVER) (STANDARD FOR U.S.A. ONLY)(#1585-)
SN: 11001-UP
1шт.
80
TRAVEL CONT LEVER AND PEDAL (FOR WRIST CONTROL LEVER)(#1001-1199)
SN: 11001-UP
1шт.
90
TRAVEL CONTROL LEVER AND PEDAL (FOR WRIST CONTROL LEVER)(#1200-)
SN: 11001-UP
1шт.
100
TRAVEL CONTROL LEVER AND PEDAL (FOR WRIST CONTROL LEVER) (STANDARD FOR U.S.A. ONLY)(#1585-)
SN: 11001-UP
1шт.
110
WORK EQUIPMENT CONTROL LEVER (FOR WRIST CONTROL LEVER)
SN: 11001-UP
1шт.
120
HYDRAULIC PIPING (P.P.C VALVE TO/FROM BLOCK) (FOR WRIST CONTROL LEVER)
SN: 11001-UP
1шт.
130
HYDRAULI PIPING (WORK EQUIPMENT CONTROL) (L.H.) (FOR WRIST CONTROL LEVER)
SN: 11001-UP
1шт.
140
HYDRAULIC PIPING (WORK EQUIPMENT CONTROL) (R.H.) (FOR WRIST CONTROL LEVER)
SN: 11001-UP
1шт.
150
REVOLVING FRAME
SN: 11001-UP
1шт.
1
07108-20516
HOSE
SN: 11001-UP
1шт.
2
273-40-52310
ELBOW
SN: 11001-UP
1шт.
4
07230-20522
UNION
SN: 11001-UP
1шт.
7
273-40-63110
TUBE
SN: 11001-UP
1шт.
11
273-40-63120
JOINT
SN: 11001-UP
1шт.
16
07236-11034
ELBOW
SN: 11001-UP
1шт.
18
705-41-01380
PUMP ASS'Y,STEERING
SN: 11001-UP
1шт.
19
02010-70632
BOLT
SN: 11001-UP
2шт.
21
02891-02081
O-RING
SN: 11001-UP
1шт.
Выбрано товаров: 36
