Запчасти Komatsu XT450L-2 7-A МОТОР ХОДА (/) МОТОР КОРПУС ХОД СИСТЕМА И ITS КОМПОНЕНТЫ

|$0

706-8J-01311

MOTOR ASSEMBLY, FINAL DRIVE

2шт.

1

706-8J-41130

CASE, MOTOR

1шт.

|$2

706-8J-00310

COVER SUBASSEMBLY, END

1шт.

2

NSS

COVER, END

1шт.

|$4

NSS

PLATE ASSEMBLY, VALVE

1шт.

3

NSS

PLATE, VALVE

1шт.

4

NSS

BUSHING

1шт.

5

NSS

BLOCK, CYLINDER

1шт.

6

NSS

PLUG

5шт.

7

706-86-71310

PIN, DOWEL

1шт.

8

708-3D-15110

VALVE

2шт.

9

708-8E-16160

PLUG

2шт.

10

07002-61023

O-RING

2шт.

11

708-8E-16250

PLUG

2шт.

12

07002-61823

O-RING

2шт.

|$15

15

-1шт.

|$16

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

16

-1шт.
