Запчасти Komatsu XT430-2 H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ( V/9 SECTION) КЛАПАН СЕКЦ. ГИДРАВЛИКА

|$0

20920KF

VALVE ASSEMBLY, DUAL FLOW MAIN CONTROL

1шт.

1

VALVE, MAIN INLET PRESSURE AND RETURN FUNCTION ( SEE FIG. H0120-04A0 )

-1шт.

2

VALVE, SAW/SHEAR FUNCTION ( SEE FIG. H0120-05A0 )

-1шт.

3

VALVE, CLAMP FUNCTION ( SEE FIG. H0120- 06A0 )

-1шт.

4

VALVE, TOOL TILT FUNCTION ( SEE FIG. H0120-07A0 )

-1шт.

5

VALVE, STICK BOOM FUNCTION ( SEE FIG. H0120-08A0 )

-1шт.

6

VALVE, MAIN BOOM FUNCTION ( SEE FIG. H0120-09A0 )

-1шт.

7

85943KF

MID ADAPTER, DUAL PUMP SYSTEM

1шт.

8

VALVE, SWING FUNCTION ( SEE FIG. H0120- 10A0 )

-1шт.

9

VALVE, ACCUMULATOR/LATERAL TILT/CLAMP FUNCTION ( SEE FIG. H0120-12A0 )

-1шт.

10

VALVE, CAB LEVELER FUNCTION ( SEE FIG. H0120-13A0 )

-1шт.

11

VALVE, CAB LEVELER FUNCTION ( SEE FIG. H0120-13A0 )

-1шт.

12

26405

VALVE, INLET PLATE

1шт.

13

955784

NUT

3шт.

14

24649

REPAIR KIT, SEAL

6шт.

15

28715KF

ROD, TIE

3шт.

16

5030371

REPAIR KIT, FACE SEALS

5шт.

17

26139

KIT, TIE ROD

3шт.

18

15530KF

NUT

3шт.

19

15528KF

WASHER

3шт.

20

28387

PLUG, PROCS ISOLATION

1шт.
