Запчасти Komatsu XT430-2 H-A ПОДАЧА, МАСЛООХЛАДИТЕЛЬ И ПРИВОД НАСОСS ГИДРАВЛИКА

1

TRIPLE PUMP DRIVE ( SEE FIG. H0240-01A0 )

-1шт.

2

15550KF

WASHER

8шт.

3

10839KF

BOLT

8шт.

4

4A1-60-10160

PUMP, TRACK DRIVE

2шт.

5

15534KF

WASHER, SAE FLAT

4шт.

6

26287KF

BOLT

4шт.

7

81271KF

PUMP, CHARGE

1шт.

8

15453

O-RING, PUMP

2шт.

9

81584KF

PUMP, AUXILIARY OIL COOLER HYDRAULIC

1шт.

|$20

OR

9

-1шт.

10

82029KF

PUMP, AUXILIARY OIL COOLER HYDRAULIC (WITH GEAR BOX COOLER OPTION)

1шт.

N/I

81643

FLANGE KIT

1шт.

|$12

28777

SEAL KIT, CHARGE PUMP

-1шт.

|$13

28393

SEAL, SHAFT

1шт.

|$14

28394

RING, SNAP

1шт.

|$15

29440

SEAL KIT, SHAFT

1шт.

|$16

29441KF

SEAL KIT

1шт.

|$17

4A1-62-10030

SEAL KIT, PUMP ASSEMBLY

1шт.

|$18

4A1-62-10040

SEAL KIT, FRONT PUMP

1шт.

|$19

4A1-62-10050

SEAL KIT, REAR PUMP

1шт.

|$21

20

-1шт.

|$22

F3 - SEAL KIT FOR PUMP WITH GEAR BOX COOLER

23

-1шт.

|$23

F3 - SEAL KIT FOR PUMP WITH GEAR BOX COOLER

23

-1шт.

|$24

F3 - SEAL KIT FOR PUMP WITH GEAR BOX COOLER

23

-1шт.
