Запчасти Komatsu XT430L-2 K-A ПЕРЕДН. ОКНАS OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

15507KF

NUT, NYLOCK

38шт.

2

15528KF

WASHER, SAE FLAT

42шт.

3

84803KF

FRAME, OUTER WINDOW (3/4 IN)

1шт.

|$51

OR

3

-1шт.

3

22262KF

FRAME, OUTER WINDOW (1-1/4 IN)

1шт.

4

4A1-54-10590

WINDOW, MAKROLON FRONT (3/4 IN)

SN: A2012--UP

1шт.

4

84801KF

WINDOW, MAKROLON FRONT (3/4 IN)

SN: A2001-A2011-UP

1шт.

|$52

OR

7

-1шт.

|$8

4A1-54-10630

WINDOW, LEXAN FRONT (1-1/4 IN)

SN: A2012--UP

1шт.

4

22264KF

WINDOW, LEXAN FRONT (1-1/4 IN)

SN: A2001-A2011-UP

1шт.

5

84804188KF

MOLDING, CHANNEL WINDOW (3/4 IN)

-2шт.

|$53

OR

11

-1шт.

5

28968188KF

MOLDING, CHANNEL WINDOW (1-1/4 IN)

-2шт.

6

84802KF

FRAME, INNER WINDOW (3/4 IN)

1шт.

|$54

OR

14

-1шт.

6

26386KF

FRAME, INNER WINDOW (1-1/4 IN)

1шт.

7

82685KF

BOLT (WITH 3/4 IN FRAME)

8шт.

|$55

OR

17

-1шт.

7

4A1-54-10090

BOLT (WITH 1-1/4 IN FRAME)

8шт.

8

4A1-54-10030

WASHER, FENDER

16шт.

N/I

4A1-54-10160

SPACER (3/4 IN)

16шт.

|$56

OR

21

-1шт.

N/I

4A1-54-10040

SPACER (1-1/4 IN)

16шт.

9

4A1-54-10560

WINDOW, FRONT CAB LIGHTS (3/4 IN)

SN: A2012--UP

1шт.

9

4A1-54-10180

WINDOW, FRONT CAB LIGHTS (3/4 IN)

SN: A2001-A2011-UP

1шт.

|$57

OR

25

-1шт.

9

4A1-54-10640

WINDOW, FRONT CAB LIGHTS (1-1/4 IN)

SN: A2012--UP

1шт.

9

4A1-54-10190

WINDOW, FRONT CAB LIGHTS (1-1/4 IN)

SN: A2001-A2011-UP

1шт.

10

4A1-54-10570

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A2012--UP

1шт.

10

4A1-54-10140

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A2001-A2011-UP

1шт.

|$58

OR

30

-1шт.

|$31

4A1-54-10660

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A2012--UP

1шт.

10

4A1-54-10060

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A2001-A2011-UP

1шт.

11

4A1-54-10580

WINDOW, R.H. TRACK VIEW (3/4 IN)

SN: A2012--UP

1шт.

11

4A1-54-10150

WINDOW, R.H. TRACK VIEW (3/4 IN)

SN: A2001-A2011-UP

1шт.

|$59

OR

35

-1шт.

11

4A1-54-10650

WINDOW, R.H. TRACK VIEW (1-1/4 IN)

SN: A2012--UP

1шт.

11

4A1-54-10050

WINDOW, R.H. TRACK VIEW (1-1/4 IN)

SN: A2001-A2011-UP

1шт.

12

4A1-54-10210

GASKET, TRACK VIEW WINDOW

2шт.

13

23604KF

LIGHT, LOWER FRONT WORK

2шт.

14

12013KF

KNOB, STAR

4шт.

15

19510KF

BOLT, EYE

4шт.

16

10731KF

BOLT (0.375 IN x 1-1/2 IN)

4шт.

17

18126193KF

WEATHERSTRIPPING

-2шт.

18

4A1-54-10220

GASKET, LOWER FRONT WORK LIGHT WINDOW

1шт.

19

4A1-54-10090

BOLT (WITH 3/4 IN FRAME)

8шт.

|$60

OR

46

-1шт.

19

4A1-54-10240

BOLT (WITH 1-1/4 IN FRAME)

8шт.

N/I

4A1-54-10170

PLATE, LIGHT BACKING

1шт.

20

10757KF

WASHER, SAE FLAT

16шт.

21

15509KF

NUT, NYLOCK

16шт.
