Запчасти Komatsu XT445L-2 E7-A MAXI HEAD СИСТЕМА УПРАВЛЕНИЯ ЭЛЕКТРИКА

1

5040093

KEYBOARD

1шт.

2

5047158

UNIT, MPU HARDWARE ELECTRONIC

1шт.

3

5053628

UNIT, FLOPPY DISK DRIVE ELECTRONIC

1шт.

4

5043716

UNIT, HBL HARDWARE ELECTRONIC

1шт.

5

5065548

JOYSTICK, RIGHT

1шт.

|$26

OR

5

-1шт.

5

5030173

JOYSTICK, LEFT (WITH RECTANGLE CONNECTOR)

1шт.

|$27

OR

7

-1шт.

5

04510379

JOYSTICK, LEFT (WITH ROUND CONNECTOR)

1шт.

6

5065547

JOYSTICK, LEFT

1шт.

|$28

OR

10

-1шт.

6

5030174

JOYSTICK, RIGHT (WITH RECTANGLE CONNECTOR)

1шт.

|$29

OR

12

-1шт.

6

04510378

JOYSTICK, RIGHT (WITH ROUND CONNECTOR)

1шт.

7

04610960

BRACKET, MAXI KEYBOARD

1шт.

8

04510380

HARNESS, CONTROL BOX INPUT

1шт.

9

04510370

BOX, MAXI HEAD 3 SERIES CONTROL

1шт.

10

04510374

HARNESS, MPU-HBL COMMUNICATION

1шт.

11

04510375

HARNESS, CONTROL BOX POWER

1шт.

12

04510376

HARNESS, JOYSTICK EXTENSION (WITH ROUND CONNECTORS)

1шт.

|$30

OR

20

-1шт.

12

04510377

HARNESS, JOYSTICK EXTENSION (WITH RECTANGLE CONNECTORS)

1шт.

N/I

00740022

CONNECTOR, DIN ELECTRICAL

16шт.

13

5029624

PRINTER

1шт.

14

5029626

PAPER

-2шт.

15

04510372

HARNESS, PRINTER

1шт.
