Запчасти Komatsu XT445L-2 U-A EXTERIOR ПЛАСТИНЫ И ТАБЛИЧКИS ( OF ) МАРКИРОВКА

1

4A1-00-10330

PLATE, L.H. XT445L-2

1шт.

2

09960-00601

DECAL, LIFTING POINT

2шт.

3

09657-03003

PLATE, SAFETY TRACK ADJUSTMENT

1шт.

4

09960-00611

DECAL, CENTER OF GRAVITY

1шт.

5

09690-P0630

PLATE, BATTERY BOX

1шт.

6

09669-0000E

DECAL, PICTOGRAM DIESEL

1шт.

7

4A1-00-10210

DECAL, TRAVEL DIRECTION

1шт.

8

4A1-00-10251

DECAL, STAY BACK

2шт.

9

09134-A1681

PLATE, KEEP OUT OF WORK AREA

1шт.

10

21917KF

DECAL, BOOM GREASE POINTS

1шт.

11

23401KF

DECAL, TELESCOPIC ARM GREASE POINTS

1шт.

12

09690-P1120

MARK

1шт.

13

09690-P0710

DECAL, KOMATSU

1шт.

14

4A1-00-10260

DECAL, DO NOT USE ETHER

1шт.

15

16916KF

DECAL, MASTER ELEC DISCONNECT

1шт.

16

28600KF

DECAL, HYDRAULIC OIL FILL

1шт.

17

28599KF

DECAL, HYDRAULIC TANK VENT

1шт.

18

85765KF

DECAL, NOTICE DO NOT SHUT OFF

1шт.

19

24086KF

DECAL, NOTICE 24 V ELECTRICAL

1шт.

20

22387KF

DECAL, ENGINE FAN ROTATION

1шт.

21

19765KF

DECAL, KEEP CLEAR OF MOVING PARTS

1шт.

22

09653-03001

DECAL, WARNING:HOT OIL HAZARD

1шт.

23

09842-A0481

DECAL, SAFETY

1шт.

24

09808-03000

DECAL, WARNING:IMPROPER USE BOOSTER

1шт.

N/I

600-023-3511

DECAL, CANADIAN EXPORT

2шт.

|$25

25

-1шт.

|$26

F1 - DECAL FOR 6 AND 8 FOOT TELESCOPIC ARMS.

26

-1шт.
