Запчасти Komatsu 430FX-1 P-A ГУСЕНИЦЫ ПРИВОД ТРУБЫ АККУМУЛЯТОР - КОРПУС ДРЕНАЖН. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

MOTOR, FINAL DRIVE ( SEE FIG. P0700-01A0 )

-1шт.

2

28910KF

HOSE ASSEMBLY (2104-12-120S-1204)

1шт.

3

4A1-60-10220

ACCUMULATOR, 15 PSI

2шт.

|$21

OR

3

-1шт.

3

28912KF

ACCUMULATOR, 30 PSI

2шт.

4

28849KF

MANIFOLD, ACCUMULATOR

2шт.

5

83554KF

HOSE ASSEMBLY (2028-12-120S-120S-W)

1шт.

6

82960KF

HOSE ASSEMBLY (2038-12-120S-12J4-W)

2шт.

7

15497KF

CONNECTOR, STRAIGHT (6400-12)

2шт.

8

28907KF

HOSE ASSEMBLY (2067-12-120S-120S-W)

2шт.

9

15484KF

ELBOW, 90 DEGREE (6801-16)

2шт.

10

15226KF

CONNECTOR, STRAIGHT (FF1852T-1216S)

2шт.

11

17688KF

ELBOW, 90 DEGREE (FF1868T-1212S)

3шт.

12

4A1-60-10210

ADAPTER, HYDRAULIC

2шт.

13

MANIFOLD, RETURN LINE (SEE FIG. H0259-01A0 )

-1шт.

N/I

15117KF

CONNECTOR, STR (FF1852T-0808S)

2шт.

N/I

19471KF

CONNECTOR

2шт.

14

17738KF

GUARD, HOSE

2шт.

15

08034-20823

BAND

6шт.

16

07002-12434

O-RING

4шт.

17

07040-12412

PLUG (M24 x 14)

2шт.

|$22

21

-1шт.

|$23

F1 - WHEN REPLACING THE OLD 30 PSI ACCUMULA TOR WITH THE NEW 15 PSI ACCUMULATOR, REPLACE BOTH ACCUMULATORS SIMILTA NEOUSLY TO AVOID OFFSETTING PSI ISSUES.

22

-1шт.
