Запчасти Komatsu 430FXL-1 K77-A ESPAR ПРЕДПУСК. ПОДОГРЕВ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

27438KF

PRE-HEATER, ESPAR

1шт.

2

27664KF

DECAL, FUEL TANK PRE-HEATER

1шт.

3

27439KF

TANK, PRE-HEATER FUEL

1шт.

4

27440KF

EXHAUST, PRE-HEATER

1шт.

5

27910060KF

INSULATION, EXHAUST PIPE

-2шт.

6

07281-00359

CLAMP, WORM STYLE HOSE (1-1/2 IN)

2шт.

7

27448KF

CLAMP, WORM STYLE (1-1/4 IN)

9шт.

8

26517KF

PROBE, PRE-HEATER

1шт.

9

27489KF

VALVE, SHUT OFF

1шт.

10

27821KF

NIPPLE, KING

2шт.

11

27816KF

TEE, BRASS

2шт.

N/I

22906KF

BREATHER

1шт.

12

4A1-923-A010

SPACER, THREADED

4шт.

13

15542KF

BOLT (3/8 IN x 3/4 IN)

6шт.

14

01643-11032

WASHER

20шт.

15

15576KF

BOLT (1/4 IN x 1 IN)

4шт.

16

10757KF

WASHER, FLAT (1/4 IN)

12шт.

17

15509KF

NUT, LOCK (1/4 IN)

10шт.

N/I

10757KF

WASHER, SAE FLAT (1/4 IN)

6шт.

N/I

15576KF

BOLT (1/4 IN x 1 IN)

2шт.

N/I

26010KF

CLAMP, HOSE (2-1/4 IN)

2шт.

18

15528KF

WASHER, SAE FLAT (3/8 IN)

3шт.

19

15507KF

NUT, LOCK (1/4 IN)

1шт.

20

22184KF

HOSE, HEATER (3/4 IN BULK)

-2шт.

21

29023KF

VALVE, BRASS BALL (3/4 IN)

1шт.

22

27709KF

ELBOW, 90 DEGREE BRASS (4501-12-12)

1шт.

23

00330510KF

ADAPTER (12 NPT-12 BARB)

1шт.

24

27711KF

SLEEVE, HOSE WRAP (96 IN)

1шт.

25

27712KF

SLEEVE, HOSE WRAP (132 IN)

1шт.

26

27820KF

NIPPLE, KING

1шт.

27

27817KF

ELBOW, 90 DEGREE (1/2 IN)

1шт.

28

15513KF

BUSHING, REDUCER (5406-12-8)

2шт.

29

82947KF

HOSE, 90 DEGREE ELBOW

2шт.

30

82948KF

CONNECTOR, HOSE (3/4 IN)

2шт.

31

10322KF

CONNECTOR, STRAIGHT SWIVEL (1404-8-8)

1шт.

32

23122KF

BUSHING (BBMK)

1шт.

33

15515KF

PLUG (5406-P-4)

1шт.

34

85895010KF

LOOM, SPLIT

1шт.

35

196770KF

PROTECTOR, SPIRAL HOSE (96 IN)

1шт.

N/I

85895144KF

LOOM, SPLIT

1шт.

N/I

85895036KF

LOOM, SPLIT

1шт.

N/I

85896078KF

LOOM, SPLIT

1шт.
