Запчасти Komatsu 450FXL-1 H-9A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ASSEMBLY ОСНОВН. СТРЕЛА SECTION ГИДРАВЛИКА

|$0

VALVE, MAIN CONTROL ( SEE FIG. H0120-02A0 OR SEE FIG. H0120-03A0 )

SN: A10001--UP

-1шт.

|$1

27266

VALVE ASSEMBLY, MAIN BOOM

SN: A10001--UP

1шт.

1

26421

PLUG, ORIFICE

SN: A10001--UP

1шт.

2

27232

COMPENSATOR

SN: A10001--UP

1шт.

3

26428

PC KIT, SPRING

SN: A10001--UP

1шт.

4

26431

SPOOL, XYZ

SN: A10001--UP

1шт.

5

26559

WASHER, SEAL

SN: A10001--UP

1шт.

6

26550

BOLT, SPOOL

SN: A10001--UP

1шт.

7

26422

PLUG, COMPENSATOR

SN: A10001--UP

1шт.

8

END CAP, A SIDE SECTION ( SEE FIG. H0120-20A0 )

SN: A10001--UP

-1шт.

9

26418

SEAL KIT, EC A SIDE

SN: A10001--UP

1шт.

10

26425

PORT RELIEF, K220

SN: A10001--UP

1шт.

11

26426KF

PLUG, PORT RELIEF

SN: A10001--UP

1шт.

12

END CAP, B SIDE SECTION ( SEE FIG. H0120-20A0 )

SN: A10001--UP

-1шт.

13

SEAL KIT, PC B SIDE ( SEE FIG. H0120- 20A0 )

SN: A10001--UP

-1шт.

14

NSS

PLUG

SN: A10001--UP

1шт.

15

NSS

PLUG, ORIFICE

SN: A10001--UP

1шт.
