Запчасти Komatsu 450FXL-1 H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН SAW/SHEAR SECTION ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|$0
VALVE, MAIN CONTROL ( SEE FIG. H0120-02A0 OR SEE FIG. H0120-03A0 )
SN: A10001--UP
-1шт.
|$1
24645
VALVE ASSEMBLY, SAW/SHEAR
SN: A10001--UP
1шт.
1
NSS
BODY, VALVE SECTION
SN: A10001--UP
1шт.
2
NSS
PLUG
SN: A10001--UP
1шт.
|$4
26421
PLUG, (0.8 MM) ORIFICE
SN: A10001--UP
1шт.
3
NSS
PLUG
SN: A10001--UP
1шт.
4
NSS
RING, BACK-UP
SN: A10001--UP
1шт.
5
NSS
O-RING
SN: A10001--UP
1шт.
|$8
27232
COMPENSATOR K3 (BLUE)
SN: A10001--UP
1шт.
6
NSS
GUIDE, SPRING
SN: A10001--UP
1шт.
7
NSS
SPRING, COMPENSATOR
SN: A10001--UP
1шт.
8
NSS
SPOOL, COMPENSATOR (BLUE)
SN: A10001--UP
1шт.
9
26428
PC KIT, SPRING
SN: A10001--UP
1шт.
10
NSS
SPOOL, PLUG
SN: A10001--UP
1шт.
11
26427KF
SPOOL, RAX ASSEMBLY
SN: A10001--UP
1шт.
12
NSS
SPOOL, PLUG
SN: A10001--UP
1шт.
13
26559
WASHER, SEAL
SN: A10001--UP
1шт.
14
26550
BOLT, SPOOL (M6 x1 MM x 8 MM)
SN: A10001--UP
1шт.
|$18
26422
SEAL KIT
SN: A10001--UP
1шт.
15
NSS
PLUG
SN: A10001--UP
1шт.
16
NSS
O-RING
SN: A10001--UP
3шт.
17
NSS
RING, BACK-UP
SN: A10001--UP
2шт.
18
END CAP, K220 A-SIDE SECTION ( SEE FIG. H0120-20A0 )
SN: A10001--UP
-1шт.
19
26418
SEAL KIT, EC A-SIDE
SN: A10001--UP
1шт.
|$24
26425
KIT, PORT RELIEF
SN: A10001--UP
1шт.
20
NSS
COVER
SN: A10001--UP
1шт.
21
NSS
SPRING, PORT RELIEF
SN: A10001--UP
2шт.
22
NSS
VALVE, PORT RELIEF
SN: A10001--UP
2шт.
|$28
27233KF
PLUG KIT, PORT RELIEF
SN: A10001--UP
1шт.
23
NSS
PLUG
SN: A10001--UP
2шт.
24
NSS
O-RING
SN: A10001--UP
2шт.
25
NSS
COVER
SN: A10001--UP
1шт.
26
NSS
SCREW, ADJUSTMENT
SN: A10001--UP
1шт.
27
NSS
NUT
SN: A10001--UP
1шт.
28
NSS
SPOOL
SN: A10001--UP
1шт.
29
NSS
O-RING
SN: A10001--UP
1шт.
30
NSS
O-RING
SN: A10001--UP
1шт.
31
END CAP, B-SIDE SECTION ( SEE FIG. H0120-20A0 )
SN: A10001--UP
-1шт.
32
SEAL KIT, PC B-SIDE ( SEE FIG. H0120- 20A0 )
SN: A10001--UP
-1шт.
Выбрано товаров: 40
