Запчасти Komatsu 450FXL-1 E-A ПЕРЕКЛЮЧАТЕЛЬ DASH ПАНЕЛЬ ЭЛЕКТРИКА

Схема запчастей Komatsu 450FXL-1 - E-A ПЕРЕКЛЮЧАТЕЛЬ DASH ПАНЕЛЬ ЭЛЕКТРИКА
31
30
4
32
30
21
16
22
17
6
24
23
7
28
25
27
26
18
19
33
8
3
9
20
12
5
1
2
14
29
10
11
15
34
13

Артикул

Название

Примечание

Количество

|$0

PANEL, DASH ( SEE FIG. E1010-01A0 )

SN: A10001--UP

-1шт.

1

01023-20310

SCREW

SN: A10001--UP

4шт.

2

01580-60302

NUT

SN: A10001--UP

4шт.

3

01601-20307

WASHER

SN: A10001--UP

4шт.

4

08034-00414

BAND

SN: A10001--UP

1шт.

5

15028KF

SWITCH, STARTING

SN: A10001--UP

1шт.

6

18288KF

BEZEL, END

SN: A10001--UP

8шт.

7

18289KF

BEZEL, CENTER

SN: A10001--UP

9шт.

8

18290KF

PLUG, BEZEL COVER

SN: A10001--UP

2шт.

9

27021KF

LAMP, RED

SN: A10001--UP

1шт.

10

27023KF

POTENTIOMETER

SN: A10001--UP

1шт.

11

27024KF

KNOB

SN: A10001--UP

1шт.

12

27025KF

BUZZER, ALARM

SN: A10001--UP

1шт.

13

27026KF

METER, SERVICE

SN: A10001--UP

1шт.

14

4A1-00-10150

PLATE, DASH PANEL DECAL

SN: A10001--UP

1шт.

15

4A1-06-10450

SWITCH, GREEN HYDRAULIC

SN: A10001--UP

1шт.

16

4A1-06-10470

SWITCH, GREEN LIGHTS

SN: A10001--UP

1шт.

17

4A1-06-10490

SWITCH, GREEN LO LIGHTS

SN: A10001--UP

1шт.

18

4A1-06-10520

LAMP, WARNING

SN: A10001--UP

1шт.

19

4A1-06-10550

LAMP, WARNING

SN: A10001--UP

1шт.

20

4A1-06-10580

LAMP, WARNING

SN: A10001--UP

1шт.

21

4A1-06-10610

SWITCH, GREEN SHIFT

SN: A10001--UP

1шт.

22

4A1-06-10620

SWITCH, BLUE HEATER

SN: A10001--UP

1шт.

23

4A1-06-10630

SWITCH, RED OIL HEATER

SN: A10001--UP

1шт.

24

4A1-06-10650

SWITCH, GREEN SAW-ON

SN: A10001--UP

1шт.

25

4A1-06-10670

SWITCH, RED SAW-OFF

SN: A10001--UP

1шт.

26

4A1-06-10690

SWITCH, GREEN HORN

SN: A10001--UP

1шт.

27

4A1-06-10710

SWITCH, REVERSE FAN

SN: A10001--UP

1шт.

28

4A1-06-10730

SWITCH, GREEN HYDRAULIC TANK VENT

SN: A10001--UP

1шт.

29

4A1-06-10750

SWITCH, RED HYDRAULIC TANK VAC

SN: A10001--UP

1шт.

30

4A1-06-10840

CLAMP, CABLE MOUNT

SN: A10001--UP

7шт.

31

4A1-06-10850

DIODE

SN: A10001--UP

2шт.

32

4A1-06-10860

RESISTOR, ALARM TERM

SN: A10001--UP

1шт.

33

4A1-06-10880

PLATE

SN: A10001--UP

1шт.

34

4A1-53-10130

PLATE, DASH PANEL

SN: A10001--UP

1шт.

Выбрано товаров: 35
