Запчасти Komatsu 450FXL-1 E-A ROPS/FOPS ПАНЕЛЬ LIGHTS ЭЛЕКТРИКА

1

ELECTRICAL CENTER, MAIN ( SEE FIG. E1000- 01A0 )

SN: A10001--UP

-1шт.

2

27247KF

HARNESS, ROPS/FOPS - WORK - TANK VACUUM

SN: A10001--UP

1шт.

3

22669

CONNECTOR

SN: A10001--UP

2шт.

N/I

22226KF

TERMINAL, MALE

SN: A10001--UP

3шт.

N/I

22225KF

SEAL, WIRE END - GREEN (WEATHER PACK)

SN: A10001--UP

3шт.

N/I

22222KF

PLUG, MALE - 3 CONTACT (WEATHER PACK)

SN: A10001--UP

1шт.

4

23292KF

LIGHT, RECTANGULAR DUAL LAMP

SN: A10001--UP

2шт.

5

NSS

BOLT

SN: A10001--UP

2шт.

6

NSS

WASHER

SN: A10001--UP

2шт.

7

NSS

NUT

SN: A10001--UP

2шт.

N/I

16705006KF

LOOM, SPLIT (0.25 IN x 6 IN)

SN: A10001--UP

1шт.
