Запчасти Komatsu 450FXL-1 E-A Э/ПРОВОДКА ДВИГАТЕЛЯ ЭЛЕКТРИКА

1

28473KF

HARNESS, ENGINE

SN: A10001--UP

1шт.

2

27447KF

SWITCH, HYDRAULIC OIL LEVEL

SN: A10001--UP

1шт.

3

25104KF

SWITCH, LIMIT (DOOR/FILL PUMP)

SN: A10001--UP

1шт.

4

25207KF

CABLE, FUEL TO ALTERNATOR

SN: A10001--UP

1шт.

5

15509KF

NUT, NYLOCK (1/4 IN)

SN: A10001--UP

6шт.

6

10756KF

WASHER, LOCK (1/4 IN)

SN: A10001--UP

6шт.

7

25208KF

BRACKET, MEGA FUSE ALTERNATOR

SN: A10001--UP

1шт.

8

22247KF

HOLDER, MEGA FUSE

SN: A10001--UP

3шт.

9

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

6шт.

10

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

6шт.

11

23619KF

FUSE, 100 AMP MEGA

SN: A10001--UP

1шт.

12

25236KF

FUSE, 150 AMP MEGA

SN: A10001--UP

1шт.

13

4A1-06-10260

FUSE, 125 AMP MEGA

SN: A10001--UP

1шт.

N/I

84215KF

CLAMP

SN: A10001--UP

18шт.

N/I

08034-20536

BAND-TIE

SN: A10001--UP

18шт.

14

25237KF

JUMPER, BUSS BAR

SN: A10001--UP

1шт.

|$16

16

-1шт.

|$17

F1 - ATTACHED TO ENGINE HOUSING FRAME.

17

-1шт.
