Запчасти Komatsu 450FXL-1 E-A АККУМУЛЯТОР ЭЛЕКТРИКА

1

15507KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

2шт.

2

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

6шт.

3

24402KF

BRACKET, TOP BATTERY HOLD-DOWN

SN: A10001--UP

1шт.

4

4A1-06-10010

BATTERY, 12V

SN: A10001--UP

2шт.

5

18735KF

WASHER, FLAT (12 MM)

SN: A10001--UP

1шт.

6

15556KF

BOLT (12 MM - 1.75P x 20 MM)

SN: A10001--UP

1шт.

7

17394KF

HARNESS, ENGINE/CHASSIS GROUND

SN: A10001--UP

1шт.

8

10813KF

NUT, LOCK (3/8 IN)

SN: A10001--UP

2шт.

9

10702KF

BOLT (3/8 IN x 2-1/5 IN)

SN: A10001--UP

2шт.

10

17261KF

BRACKET, BOTTOM BATTERY HOLD-DOWN

SN: A10001--UP

1шт.

N/I

4A1-06-10112

COVER, BATTERY

SN: A10001--UP

1шт.

N/I

4A1-06-10220

BRACKET

SN: A10001--UP

1шт.

N/I

4A1-06-10121

PLATE, BRACKET

SN: A10001--UP

1шт.

N/I

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

2шт.

N/I

4A1-06-10230

NUT, WING

SN: A10001--UP

2шт.

N/I

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

2шт.
