Запчасти Komatsu 450FXL-1 V-8A FIRE SUPPRESSION СИСТЕМА FEED ЛИНИЯ АКСЕССУАРЫ

1

TEE, DISTRIBUTION ( SEE FIG. V0100-07A0 )

SN: A10001--UP

-1шт.

2

10359KF

ELBOW

SN: A10001--UP

1шт.

3

11707KF

BOLT (3/8 IN x 1 IN)

SN: A10001--UP

2шт.

4

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

2шт.

5

28571KF

HOSE ASSEMBLY

SN: A10001--UP

1шт.

6

28567KF

HOSE ASSEMBLY

SN: A10001--UP

1шт.

7

11374

ELBOW

SN: A10001--UP

1шт.

8

28559KF

MANIFOLD, FIRE SUPPRESSION DISTRIBUTION

SN: A10001--UP

1шт.

9

16775

NOZZLE

SN: A10001--UP

1шт.

10

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

4шт.

11

10824KF

BOLT

SN: A10001--UP

2шт.

12

10395KF

ELBOW

SN: A10001--UP

1шт.

13

28560KF

MANIFOLD, FIRE SUPPRESSION DISTRIBUTION

SN: A10001--UP

1шт.

14

28564KF

HOSE ASSEMBLY

SN: A10001--UP

1шт.

15

11707KF

BOLT (3/8 IN x 1 IN)

SN: A10001--UP

1шт.

16

10802KF

WASHER (0.375 IN)

SN: A10001--UP

1шт.

17

4A1-62-10330

MANIFOLD, FIRE SUPPRESSION DISTRIBUTION

SN: A10001--UP

1шт.

18

17837KF

NOZZLE

SN: A10001--UP

1шт.

19

10788KF

NUT, NYLOCK (5/16 IN)

SN: A10001--UP

2шт.

20

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

8шт.

21

15568KF

BOLT

SN: A10001--UP

4шт.

22

10811KF

NUT, LOCK (1/4 IN)

SN: A10001--UP

4шт.

|$22

22

-1шт.

|$23

F1 - THIS PART IS AVAILABLE FROM AUTHORIZED ANSUL DISTRIBUTORS ONLY.

23

-1шт.
