Запчасти Komatsu 450FXL-1 V-A FIRE SUPPRESSION СИСТЕМА PNЕСМАТЕРИАЛIC АКТУАТОР АКСЕССУАРЫ

|$0

21248

ACTUATOR ASSEMBLY, PNEUMATIC

SN: A10001--UP

1шт.

1

21249

BODY, UPPER ACTUATOR

SN: A10001--UP

1шт.

2

21250

O-RING, SLAVE PISTON

SN: A10001--UP

1шт.

3

21251

PISTON, PNEUMATIC SLAVE

SN: A10001--UP

1шт.

4

21252

PIN, PUNCTURE

SN: A10001--UP

1шт.

5

21253

SPRING

SN: A10001--UP

1шт.

6

21254

O-RING, ACTUATOR BODY

SN: A10001--UP

1шт.

7

21255

BODY, LOWER ACTUATOR

SN: A10001--UP

1шт.

8

21256

WASHER

SN: A10001--UP

1шт.

9

21257

RING, RETAINING

SN: A10001--UP

1шт.

10

21258

GASKET

SN: A10001--UP

1шт.

11

21276

CARTRIDGE, NITROGEN

SN: A10001--UP

1шт.

|$12

21260

BRACKET ASSEMBLY, NITROGEN CARTRIDGE

SN: A10001--UP

1шт.

12

NSS

BRACKET, NITROGEN CARTRIDGE

SN: A10001--UP

1шт.

13

21261

ARM, CLAMP

SN: A10001--UP

1шт.

N/I

21262

PAD, CLAMP ARM

SN: A10001--UP

1шт.

14

15507KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

1шт.

15

21263

BOLT, CARRIAGE

SN: A10001--UP

2шт.

|$18

18

-1шт.

|$19

F1 - THIS PART IS AVAILABLE FROM AUTHORIZED ANSUL DISTRIBUTORS ONLY.

19

-1шт.
