Запчасти Komatsu 450FXL-1 T-A РАБОЧЕЕ ОБОРУДОВАНИЕ ТРУБКА ЛИНИИ ЛИНИЯ ТЕЛЕСКОП. РУКОЯТИS РАБОЧЕЕ ОБОРУДОВАНИЕ

1

ARM, TELESCOPIC ( SEE FIG. T3000-01A0 )

SN: A10001--UP

-1шт.

2

22959KF

TUBE (1 IN x 60 IN)

SN: A10001--UP

3шт.

3

26512KF

TUBE (1 IN x 60 IN ELECTRICAL WIRE)

SN: A10001--UP

1шт.

4

12447KF

CLAMP, SADDLE TOP TUBE (1 IN x 1 IN)

SN: A10001--UP

4шт.

5

22958KF

TUBE (1/2 IN x 60 IN)

SN: A10001--UP

2шт.

6

15272KF

CLAMP, SADDLE TOP TUBE (1/2 IN x 1/2 IN)

SN: A10001--UP

2шт.

7

10723KF

BOLT (4-1/2 IN x 5/8 IN)

SN: A10001--UP

2шт.

8

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

4шт.

9

15517KF

BOLT (5/8 IN x 2-1/2 IN)

SN: A10001--UP

2шт.

10

26513KF

COVER, ELECTRICAL WIRE TUBE

SN: A10001--UP

1шт.

11

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

2шт.

12

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

2шт.

13

15436KF

CAP (FF9863-16S)

SN: A10001--UP

2шт.

14

15437KF

CAP (FF9863-12S)

SN: A10001--UP

1шт.

15

15462KF

CAP (304-16)

SN: A10001--UP

1шт.
