Запчасти Komatsu 450FXL-1 D-A CONTINUOUS ROTATION ТОПЛИВН. СИСТЕМА ТОПЛИВН. БАК. TO ПОВОРОТН. КОЛЛЕКТОР ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

16360KF

ELBOW

SN: A10001--UP

2шт.

2

83202KF

HOSE ASSEMBLY (2090-08-08JS-0804-WS125)

SN: A10001--UP

1шт.

3

83201KF

HOSE ASSEMBLY (2053-04-040S-0409-WS100)

SN: A10001--UP

1шт.

4

BRACKET, FUEL PUMP/FILTER ( SEE FIG. D0200-05A0 )

SN: A10001--UP

-1шт.

5

15490KF

CONNECTOR, STR (6400-8-10)

SN: A10001--UP

2шт.

6

16010KF

CONNECTOR, STR (2404-8-6)

SN: A10001--UP

2шт.

7

17085KF

ELBOW, 90 DEGREE SWIVEL (6500-8)

SN: A10001--UP

1шт.

8

24896KF

HOSE ASSEMBLY (2015-08-08JS-08J9-W)

SN: A10001--UP

1шт.

9

15652KF

VALVE, HYDRAULIC/FUEL TANK CHECK

SN: A10001--UP

1шт.

10

22405KF

ELBOW, 90 DEGREE (8-6 C50L0-S)

SN: A10001--UP

1шт.

11

83204KF

HOSE ASSEMBLY (2085-08-08JS-080S)

SN: A10001--UP

1шт.

12

16297KF

ELBOW, 90 DEGREE SWIVEL (FF2098T-0808S)

SN: A10001--UP

1шт.

13

15457KF

CONNECTOR, STR (8 ORFS MX6 ORB M)

SN: A10001--UP

1шт.
