Запчасти Komatsu 450FXL-1 T-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН - ОСНОВН. ГИДРОЛИНИЯ СТРЕЛЫ PRESSURE & ВОЗВРАТНАЯ ЛИНИЯ - PROCESSING HEADS РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

18397KF

CONNECTOR, FLANGE PAD (W48-16-16U CODE 62)

SN: A10001--UP

1шт.

1

NSS

PAD, FLANGE

SN: A10001--UP

1шт.

2

15389KF

O-RING (1-1/2 IN SF - CODE 61/62)

SN: A10001--UP

1шт.

3

NSS

WASHER

SN: A10001--UP

4шт.

4

26146KF

BUSHING, REDUCER (6410-16-20)

SN: A10001--UP

1шт.

5

22266KF

CONNECTOR

SN: A10001--UP

1шт.

6

27938KF

HOSE ASSEMBLY (6064-20-200S-2004-W)

SN: A10001--UP

1шт.

7

22617KF

HOSE ASSEMBLY (2071-20-200S-2004-W)

SN: A10001--UP

1шт.

8

17055KF

ELBOW, 90 DEGREE (20-20 C50L0-S)

SN: A10001--UP

1шт.

9

20992KF

PLUG

SN: A10001--UP

4шт.

|$10

15111KF

FLANGE KIT, SPLIT (1 IN CODE 61)

SN: A10001--UP

4шт.

10

NSS

FLANGE, SPLIT

SN: A10001--UP

4шт.

11

15377

O-RING (1 IN SF)

SN: A10001--UP

1шт.

12

NSS

WASHER

SN: A10001--UP

1шт.

13

16116

BOLT (10 MM - 1.5P x 30 MM)

SN: A10001--UP

16шт.

14

28292KF

CONNECTOR, STRAIGHT ADJUSTABLE

SN: A10001--UP

2шт.

15

18954KF

BOLT (12 MM -1.75 x 40 MM)

SN: A10001--UP

16шт.

16

28292KF

CONNECTOR, STRAIGHT ADJUSTABLE

SN: A10001--UP

1шт.

17

25606KF

VALVE, BALL (PRESSURE SHUT OFF TO ATTACHMENT)

SN: A10001--UP

1шт.

18

19473KF

CONNECTOR, STRAIGHT (6403-16)

SN: A10001--UP

1шт.

19

18950KF

PLUG (6408-HHP-20)

SN: A10001--UP

1шт.
