Запчасти Komatsu 450FXL-1 T-A ИНСТРУМЕНТ ЦИЛИНДР ПЕРЕКОСА КРЕПЛЕНИЕ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

15549KF

BOLT (3/4 IN x 2 IN)

SN: A10001--UP

2шт.

2

15550KF

WASHER, SAE FLAT (3/4 IN)

SN: A10001--UP

2шт.

3

18570KF

BUSHING, PIN RETAINING

SN: A10001--UP

2шт.

4

81634KF

PIN

SN: A10001--UP

2шт.

5

14243KF

SPACER

SN: A10001--UP

1шт.

6

22451KF

BAR KIT, TOP CONNECTING LINK

SN: A10001--UP

2шт.

7

14241KF

BUSHING (2-1/2 IN x 3 IN)

SN: A10001--UP

2шт.

N/I

14240KF

BAR, LINK

SN: A10001--UP

1шт.

8

10704KF

FITTING, GREASE (0.125 NPT - STR)

SN: A10001--UP

2шт.

9

84800KF

SHIM

SN: A10001--UP

2шт.

10

10728KF

NUT, ZINC PLATED NYLOCK (2 IN - 12)

SN: A10001--UP

2шт.

11

CYLINDER, TOOL TILT ( SEE FIG. T0100- 01A0 )

SN: A10001--UP

-1шт.

12

10719KF

BOLT (5/8 IN x 4 IN)

SN: A10001--UP

1шт.

13

81631KF

PIN

SN: A10001--UP

1шт.

14

15563KF

NUT

SN: A10001--UP

1шт.

15

22450KF

BAR KIT, L.H. CONNECTING LINK

SN: A10001--UP

1шт.

N/I

14239KF

BAR, LINK

SN: A10001--UP

1шт.

N/I

14242KF

BUSHING

SN: A10001--UP

2шт.

16

28939KF

BAR KIT, R.H. CONNECTING LINK

SN: A10001--UP

1шт.

N/I

28938KF

BAR, LINK

SN: A10001--UP

1шт.

17

14242KF

BUSHING

SN: A10001--UP

2шт.

18

21671KF

ELBOW

SN: A10001--UP

2шт.

19

10704KF

FITTING, GREASE (0.125 NPT - STR)

SN: A10001--UP

2шт.
