Запчасти Komatsu 450FXL-1 T-A ИНСТРУМЕНТ ЦИЛИНДР ПЕРЕКОСА РАБОЧЕЕ ОБОРУДОВАНИЕ

Схема запчастей Komatsu 450FXL-1 - T-A ИНСТРУМЕНТ ЦИЛИНДР ПЕРЕКОСА РАБОЧЕЕ ОБОРУДОВАНИЕ
1
3
2
17
16
15
21
14
13
12
11
10
22
20
9
8
5
7
6
5
4
18
19

Артикул

Название

Примечание

Количество

|$0

4A1-6C-10310

CYLINDER ASSEMBLY, TOOL TILT

SN: A10001--UP

1шт.

1

22985KF

ASSEMBLY KIT, BARREL

SN: A10001--UP

1шт.

2

14241KF

BUSHING (2-1/2 IN x 3 IN)

SN: A10001--UP

2шт.

3

15683KF

FITTING, GREASE

SN: A10001--UP

2шт.

4

24563KF

BOLT, CYLINDER ROD

SN: A10001--UP

1шт.

5

NSS

RING, PISTON WEAR

SN: A10001--UP

2шт.

6

NSS

RING, PISTON SQUARE

SN: A10001--UP

1шт.

7

NSS

RING, PISTON CHEM-CAST

SN: A10001--UP

1шт.

8

NSS

RING, PISTON WEAR

SN: A10001--UP

1шт.

9

NSS

O-RING, PISTON

SN: A10001--UP

1шт.

10

4A1-6C-10330

PISTON ASSEMBLY

SN: A10001--UP

1шт.

11

NSS

RING, ROD BEARING WEAR

SN: A10001--UP

1шт.

12

NSS

O-RING, ROD BEARING

SN: A10001--UP

1шт.

13

NSS

RING, ROD BEARING BACK-UP

SN: A10001--UP

1шт.

14

4A1-6C-10320

HEAD ASSEMBLY, CYLINDER

SN: A10001--UP

1шт.

15

4A1-6C-10340

BOLT

SN: A10001--UP

12шт.

16

NSS

U-CUP, ROD BEARING

SN: A10001--UP

1шт.

17

NSS

WIPER, ROD

SN: A10001--UP

1шт.

18

22537KF

ROD ASSEMBLY

SN: A10001--UP

1шт.

19

14241KF

BUSHING (2-1/2 IN x 3 IN)

SN: A10001--UP

2шт.

20

10704KF

FITTING, GREASE (0.125 NPT - STR)

SN: A10001--UP

1шт.

21

4A1-6C-10040

WASHER

SN: A10001--UP

12шт.

22

4A1-30-10280

WASHER

SN: A10001--UP

1шт.

|$23

22988KF

REPAIR KIT, MAIN BOOM SEAL

SN: A10001--UP

1шт.

|$24

4A1-6C-10650

RING, WEAR

SN: A10001--UP

1шт.

|$25

4A1-6C-10660

PACKING, ROD

SN: A10001--UP

1шт.

|$26

4A1-6C-10370

SEAL, DUST

SN: A10001--UP

1шт.

|$27

4A1-6C-10670

O-RING

SN: A10001--UP

1шт.

|$28

4A1-6C-10680

RING, BACK-UP

SN: A10001--UP

1шт.

|$29

4A1-6C-10690

RING, BUFFER

SN: A10001--UP

1шт.

|$30

4A1-6C-10270

RING, WEAR

SN: A10001--UP

2шт.

|$31

4A1-6C-10260

RING, PISTON

SN: A10001--UP

1шт.

|$32

4A1-6C-10290

PACKING, PISTON

SN: A10001--UP

2шт.

|$33

4A1-6C-10280

O-RING

SN: A10001--UP

1шт.

|$34

34

-1шт.

|$35

F1 - PART INCLUDED IN SERVICE KIT:

35

-1шт.

Выбрано товаров: 36
