Запчасти Komatsu 450FXL-1 T-A ОСНОВН. ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

Схема запчастей Komatsu 450FXL-1 - T-A ОСНОВН. ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
15
14
13
19
12
11
10
9
8
7
4
6
5
4
18
3
17
16

Артикул

Название

Примечание

Количество

|$0

4A1-6C-10510

CYLINDER ASSEMBLY, MAIN BOOM

SN: A10001--UP

1шт.

1

22375KF

ASSEMBLY KIT, BARREL

SN: A10001--UP

1шт.

2

11706KF

BUSHING (3 IN ID x 3-1/2 IN OD X 4-1/4 IN)

SN: A10001--UP

2шт.

3

16561KF

NUT, CYLINDER ROD

SN: A10001--UP

1шт.

4

NSS

RING, PISTON WEAR

SN: A10001--UP

2шт.

5

NSS

RING, PISTON SQUARE

SN: A10001--UP

1шт.

6

NSS

RING, PISTON CHEM-CAST

SN: A10001--UP

1шт.

7

NSS

O-RING, PISTON

SN: A10001--UP

1шт.

|$8

4A1-6C-10530

PISTON ASSEMBLY

SN: A10001--UP

1шт.

8

NSS

PISTON

SN: A10001--UP

1шт.

9

NSS

RING, ROD BEARING WEAR

SN: A10001--UP

1шт.

10

NSS

O-RING, ROD BEARING

SN: A10001--UP

1шт.

11

NSS

RING, ROD BEARING BACK-UP

SN: A10001--UP

1шт.

12

4A1-6C-10520

HEAD, CYLINDER

SN: A10001--UP

1шт.

13

4A1-6C-10340

BOLT

SN: A10001--UP

12шт.

14

NSS

U-CUP, ROD BEARING

SN: A10001--UP

1шт.

15

NSS

WIPER, ROD

SN: A10001--UP

1шт.

16

18282KF

ROD ASSEMBLY

SN: A10001--UP

1шт.

17

10704KF

FITTING, GREASE (0.125 NPT - STR)

SN: A10001--UP

1шт.

18

11706KF

BUSHING

SN: A10001--UP

1шт.

19

4A1-6C-10040

WASHER

SN: A10001--UP

12шт.

|$21

24570KF

REPAIR KIT, MAIN BOOM SEAL

SN: A10001--UP

1шт.

|$22

4A1-6C-10620

PACKING, ROD

SN: A10001--UP

1шт.

|$23

4A1-6C-10610

RING, WEAR

SN: A10001--UP

1шт.

|$24

4A1-30-10150

O-RING

SN: A10001--UP

1шт.

|$25

4A1-30-10160

RING, BACK-UP

SN: A10001--UP

1шт.

|$26

4A1-6C-10540

RING, BUFFER

SN: A10001--UP

1шт.

|$27

4A1-6C-10570

SEAL, DUST

SN: A10001--UP

1шт.

|$28

4A1-30-10230

RING, PISTON

SN: A10001--UP

1шт.

|$29

4A1-6C-10630

RING, WEAR

SN: A10001--UP

2шт.

|$30

4A1-6C-10640

O-RING

SN: A10001--UP

1шт.

|$31

31

-1шт.

|$32

F1 - PART INCLUDED IN SERVICE KIT:

32

-1шт.

Выбрано товаров: 33
