Запчасти Komatsu 450FXL-1 R-A ПРАВ. КАБИНА УРОВЕНЬING СМАЗ. ЛИНИИ НИЖН.CARRIAGE

|$0

21146KF

HOSE KIT, GREASE LINES

SN: A10001--UP

1шт.

1

NSS

GREASE HOSE, LOWER TURNTABLE FRONT PIVOT

SN: A10001--UP

1шт.

2

NSS

GREASE HOSE, LOWER TURNTABLE SLACK ADJUSTER

SN: A10001--UP

1шт.

3

NSS

GREASE HOSE, INTERMEDIATE PIVOT

SN: A10001--UP

1шт.

4

NSS

GREASE HOSE, INTERMEDIATE PIVOT

SN: A10001--UP

1шт.

5

NSS

GREASE HOSE, INTERMEDIATE PIVOT

SN: A10001--UP

1шт.

6

NSS

GREASE HOSE, CAB LEVEL CYLINDER ROD

SN: A10001--UP

1шт.

7

NSS

GREASE HOSE, CAB LEVEL CYLINDER BASE

SN: A10001--UP

1шт.

8

10704KF

FITTING, GREASE (0.125 NPT - STR)

SN: A10001--UP

7шт.

9

15658KF

CONNECTOR, STRAIGHT BULKHEAD (2239-2-4S)

SN: A10001--UP

7шт.

10

16808KF

BUSHING, REDUCER (5406-8-2)

SN: A10001--UP

1шт.

11

15391KF

CONNECTOR, STRAIGHT SWIVEL (1404-2-2)

SN: A10001--UP

2шт.

12

15657KF

ELBOW, 90 DEGREE SWIVEL (1501-2-2)

SN: A10001--UP

4шт.

13

21549KF

CONNECTOR, STR (5405-2-2)

SN: A10001--UP

3шт.

14

21617KF

ELBOW, 45 DEGREE SWIVEL (1503-2-2)

SN: A10001--UP

2шт.

15

28876

HOSE ASSEMBLY, GREASE LINE EXTENSION

SN: A10001--UP

1шт.

N/I

04434-52711

CLIP

SN: A10001--UP

2шт.

N/I

15528KF

WASHER

SN: A10001--UP

2шт.

N/I

11707KF

BOLT

SN: A10001--UP

2шт.
