Запчасти Komatsu 450FXL-1 R-A УРОВЕНЬING ЦИЛИНДР КРЕПЛЕНИЕ НИЖН.CARRIAGE

1

BASE, 4-WAY LEVELING ( SEE FIG. R4100- 01A0 )

SN: A10001--UP

-1шт.

2

10728KF

NUT, NYLOCK

SN: A10001--UP

2шт.

3

12021KF

WASHER, BURNED (2.13 ID x 4 OD x 0.5)

SN: A10001--UP

1шт.

4

81804KF

HUB, TAPERED

SN: A10001--UP

1шт.

5

82578KF

PIN, LEVELER (3.5 IN)

SN: A10001--UP

1шт.

6

81805KF

SPACER (3.51 IN ID x 4.5 IN OD x 0.875)

SN: A10001--UP

1шт.

7

81888KF

WASHER (2.09 IN ID x 4 IN OD x 0.75 IN)

SN: A10001--UP

1шт.

8

10733KF

BOLT (1 IN x 3 IN)

SN: A10001--UP

4шт.

9

15579KF

WASHER, SAE FLAT (1 IN)

SN: A10001--UP

4шт.

10

81808KF

TAKE UP, KEEPER PIN

SN: A10001--UP

1шт.

11

81807KF

HUB, TAPERED PIN (3.5 IN)

SN: A10001--UP

2шт.

12

82046KF

SPACER (3.51 IN ID x 4.5 IN OD x 0.75 IN)

SN: A10001--UP

2шт.

13

81806KF

PIN, TAPERED (3.5 IN)

SN: A10001--UP

1шт.

14

81879KF

WASHER (1.06 IN ID x 4.5 IN OD x 0.5 IN)

SN: A10001--UP

1шт.

15

82559KF

SPACER, TAPER (3.5 IN)

SN: A10001--UP

1шт.
