Запчасти Komatsu 450FXL-1 R-A УРОВЕНЬING ЦИЛИНДР НИЖН.CARRIAGE

|$0

4A1-6C-10110

CYLINDER, LEVELING

SN: A10001--UP

2шт.

1

4A1-6C-10130

CYLINDER ASSEMBLY

SN: A10001--UP

1шт.

2

4A1-6C-10170

ROD ASSEMBLY, PISTON

SN: A10001--UP

1шт.

3

28693KF

PISTON ASSEMBLY

SN: A10001--UP

1шт.

4

4A1-6C-10120

HEAD, CYLINDER ASSEMBLY

SN: A10001--UP

1шт.

N/I

4A1-6C-10160

SPACER

SN: A10001--UP

1шт.

5

19956KF

BOLT (ASTM A354, GD BD 2 IN - 12 x 4.5 IN)

SN: A10001--UP

1шт.

6

4A1-30-10280

WASHER

SN: A10001--UP

1шт.

7

4A1-6C-10040

WASHER

SN: A10001--UP

16шт.

8

4A1-6C-10030

BOLT

SN: A10001--UP

16шт.

9

28697KF

VALVE, RELIEF

SN: A10001--UP

1шт.

|$23

SERVICE KIT

11

-1шт.

N/I

28698KF

KIT, SEAL

SN: A10001--UP

1шт.

N/I

4A1-30-10120

ROD, PACKING

SN: A10001--UP

1шт.

N/I

4A1-30-10170

RING, BUFFER

SN: A10001--UP

1шт.

N/I

4A1-30-10140

RING, WEAR

SN: A10001--UP

1шт.

N/I

4A1-6C-10240

O-RING

SN: A10001--UP

1шт.

N/I

4A1-6C-10250

RING, BACK-UP

SN: A10001--UP

1шт.

N/I

4A1-30-10130

SEAL, DUST

SN: A10001--UP

1шт.

N/I

4A1-6C-10220

RING, PISTON

SN: A10001--UP

1шт.

N/I

4A1-6C-10230

RING, WEAR

SN: A10001--UP

2шт.

N/I

4A1-30-10270

O-RING

SN: A10001--UP

1шт.

N/I

4A1-30-10290

RING, BACK-UP

SN: A10001--UP

1шт.
