Запчасти Komatsu 450FXL-1 R-A -WAY УРОВЕНЬING ОСНОВ. НИЖН.CARRIAGE

1

82045KF

SUPPORT, LEVELING

SN: A10001--UP

1шт.

2

82528KF

SUPPORT, LOWER LEVELING

SN: A10001--UP

1шт.

3

81883KF

PIN, LEVELER PIVOT

SN: A10001--UP

1шт.

4

81886KF

NUT (2.25 IN NYLOCK)

SN: A10001--UP

2шт.

5

81887KF

WASHER (2.34 IN ID x 4.25 IN OD x 0.75 IN)

SN: A10001--UP

2шт.

6

82042KF

BUSHING (3.5 IN ID x 4.25 IN OD x 5 IN)

SN: A10001--UP

1шт.

7

82177KF

PIN, LEVELER (3.5 IN)

SN: A10001--UP

1шт.

8

81885KF

WASHER, THRUST

SN: A10001--UP

1шт.

9

81884KF

HUB, TAPERED

SN: A10001--UP

2шт.

10

81881KF

PLATE, CLAMPING

SN: A10001--UP

2шт.

11

81882KF

PLATE, BOLT LOCK

SN: A10001--UP

2шт.

12

15534KF

WASHER, FLAT (SAE 0.5 IN)

SN: A10001--UP

12шт.

13

15565KF

BOLT (1/2 IN x 2-1/2 IN)

SN: A10001--UP

12шт.

14

82178KF

SCREW, WITH SHOULDER (1 IN x 4.25 IN)

SN: A10001--UP

2шт.

15

19073KF

NUT, HEX (1 IN)

SN: A10001--UP

2шт.

16

82040KF

PLATE, THRUST (3.5 IN)

SN: A10001--UP

1шт.

17

82041KF

BUSHING (3.5 IN ID x 4.25 IN OD x 4.25 IN)

SN: A10001--UP

3шт.

18

15552KF

BOLT (1 IN x 2-1/2 IN)

SN: A10001--UP

2шт.
