Запчасти Komatsu 450FXL-1 P-A CONTINUOUS ROTATION ГУСЕНИЦЫ КОРПУС ПРИВОДА ДРЕНАЖН. ТРУБЫ АККУМУЛЯТОР - КОРПУС ДРЕНАЖН. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

MOTOR, FINAL DRIVE ( SEE FIG. P0700-01A0 )

SN: A10001--UP

-1шт.

2

15531KF

STUD, THREADED (10 MM x 45 MM)

SN: A10001--UP

2шт.

3

NUT

SN: A10001--UP

2шт.

4

83030KF

HOSE ASSEMBLY (2036.5-12-120S-120S-W)

SN: A10001--UP

1шт.

5

83029KF

HOSE ASSEMBLY (2019-12-12JS-120S)

SN: A10001--UP

2шт.

6

28912KF

ACCUMULATOR, 30 PSI

SN: A10001--UP

2шт.

7

15497KF

CONNECTOR, STRAIGHT (6400-12)

SN: A10001--UP

2шт.

8

15526KF

CONNECTOR, STRAIGHT (FF1852T-1216S)

SN: A10001--UP

2шт.

9

28849KF

MANIFOLD, ACCUMULATOR

SN: A10001--UP

2шт.

10

17688KF

ELBOW, 90 DEGREE (FF1868T-1216S)

SN: A10001--UP

2шт.

11

15228KF

ELBOW, 90 DEGREE (FF1868T-1616S)

SN: A10001--UP

2шт.

12

83028KF

HOSE ASSEMBLY (2032-12-120S-12J4)

SN: A10001--UP

2шт.

13

4A1-60-10210

ADAPTER, HYDRAULIC

SN: A10001--UP

2шт.

14

07002-12434

O-RING

SN: A10001--UP

4шт.

15

07040-12412

PLUG (M24 x 14)

SN: A10001--UP

2шт.
