Запчасти Komatsu 450FXL-1 N9-A МОТОР ПОВОРОТА СМАЗ. ЛИНИИ ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

15529KF

BOLT (3/8 IN x 2 IN)

SN: A10001--UP

1шт.

2

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

8шт.

3

19758

GUARD, SWING BEARING GREASE PORT

SN: A10001--UP

1шт.

4

10813KF

NUT, LOCK (3/8 IN)

SN: A10001--UP

1шт.

5

15657KF

ELBOW, 90 DEGREE SWIVEL (1501-2-2)

SN: A10001--UP

1шт.

6

15391KF

CONNECTOR, STR SWIVEL (1404-2-2)

SN: A10001--UP

1шт.

7

83153KF

HOSE ASSEMBLY (2046-02-02PS-02PS)

SN: A10001--UP

2шт.

8

21617KF

ELBOW, 45 DEGREE SWIVEL (1503-2-2)

SN: A10001--UP

2шт.

9

15685KF

FITTING, STRAIGHT LONG GREASE (1/8 IN THREAD)

SN: A10001--UP

2шт.

10

10731KF

BOLT (0.375 IN x 1-1/2 IN)

SN: A10001--UP

4шт.

11

18248KF

COVER, GREASE CUP

SN: A10001--UP

1шт.

12

26713KF

INSULATION, SOUNDPROOF GREASE CUP

SN: A10001--UP

1шт.

13

15685KF

FITTING, STRAIGHT LONG GREASE (1/8 IN THREAD)

SN: A10001--UP

1шт.

14

15658KF

CONNECTOR, STR BULKHEAD (2239-2-4S)

SN: A10001--UP

1шт.

15

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

2шт.

16

17612KF

CUP, SWING BEARING BULKHEAD GREASE

SN: A10001--UP

1шт.

17

19887KF

MAT, CAB FLOOR

SN: A10001--UP

1шт.

18

4A1-25-10030

CUP, GREASE

SN: A10001--UP

1шт.

19

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

2шт.

20

84669KF

BOLT (.625 IN x 1.25 IN)

SN: A10001--UP

2шт.

21

4A1-25-10010

HOSE

SN: A10001--UP

1шт.

22

17257KF

CLAMP, STRAP-COATED HOSE

SN: A10001--UP

1шт.

N/I

84551KF

FOAM, SOUND (3 IN)

SN: A10001--UP

2шт.
