Запчасти Komatsu 450FXL-1 M-A РАДИАТОР ПОВОРОТН.-OUT ЧАСТИ КОРПУСА ЧАСТИ КОРПУСА

1

27030KF

GUARD, RADIATOR SUPPORT

SN: A10001--UP

1шт.

2

10893KF

BOLT (1/2 IN x 3 IN)

SN: A10001--UP

4шт.

3

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

6шт.

4

19772KF

LATCH, RADIATOR GUARD CAM

SN: A10001--UP

2шт.

5

18126KF

WEATHERSTRIPPING

SN: A10001--UP

-2шт.

6

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

2шт.

7

10705KF

BOLT (1/2 IN x 5 IN)

SN: A10001--UP

2шт.

8

26752KF

SCREEN, HINGED RADIATOR PROTECTION

SN: A10001--UP

1шт.

9

27032KF

GUARD, SWING-OUT RADIATOR

SN: A10001--UP

1шт.

10

10783KF

BOLT (1/2 IN x 1 IN)

SN: A10001--UP

2шт.

11

16403KF

BRACKET, HINGE

SN: A10001--UP

2шт.

12

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

14шт.

13

24542KF

LATCH, SCREEN

SN: A10001--UP

1шт.

14

15576KF

BOLT (1/4 IN x 1 IN)

SN: A10001--UP

1шт.

15

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

9шт.

16

10800KF

WASHER, FLAT (1/4 IN)

SN: A10001--UP

3шт.

17

24719

FOAM

SN: A10001--UP

1шт.

18

27033KF

PLATE, RADIATOR GUARD COVER

SN: A10001--UP

1шт.

19

10756KF

WASHER, LOCK (1/4 IN)

SN: A10001--UP

6шт.

20

FRAME, ENGINE HOUSING ( SEE FIG. J0150- 01A0 )

SN: A10001--UP

-1шт.
