Запчасти Komatsu 450FXL-1 K7-A КОНДИЦ. ВОЗДУХА КОМПРЕССОР И КРЕПЛЕНИЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

24607

BRACKET, COMPRESSOR MOUNTING

SN: A10001--UP

1шт.

2

24605

BOLT (10 MM x 1.5P x 39 MM)

SN: A10001--UP

4шт.

3

15530KF

NUT (10 MM - 1.5P)

SN: A10001--UP

8шт.

4

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

7шт.

5

24608

SCREW, COMPRESSOR ADJUSTMENT

SN: A10001--UP

1шт.

6

24609

BOLT (10 MM - 1.5P x 50 MM)

SN: A10001--UP

2шт.

7

24606

BLOCK, ADJUSTMENT

SN: A10001--UP

1шт.

8

18735KF

WASHER, FLAT (12 MM)

SN: A10001--UP

1шт.

9

955784

NUT, HEX (12 MM-1.75P)

SN: A10001--UP

1шт.

10

24604

BOLT (10 MM - 1.5P x 125 MM)

SN: A10001--UP

1шт.

11

23278KF

COMPRESSOR, 24V AIR CONDITIONER

SN: A10001--UP

1шт.

12

16796KF

COVER, COMPRESSOR DUST

SN: A10001--UP

1шт.

13

NSS

BOLT

SN: A10001--UP

3шт.

14

01010-81035

BOLT

SN: A10001--UP

1шт.

15

01643-31032

WASHER

SN: A10001--UP

2шт.

16

01580-11008

NUT

SN: A10001--UP

1шт.

N/I

04434-51010

CLIP

SN: A10001--UP

1шт.

N/I

26499KF

DECAL, R-134A WARNING

SN: A10001--UP

1шт.
