Запчасти Komatsu 450FXL-1 K7-A КОНДИЦ. ВОЗДУХА И ОБОГРЕВАТЕЛЬ. OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

26497KF

AIR CONDITIONER AND HEATER ASSEMBLY

SN: A10001--UP

1шт.

1

NSS

HOUSING, BOTTOM

SN: A10001--UP

1шт.

2

22253

DIFFUSER ASSEMBLY

SN: A10001--UP

4шт.

3

22255

KNOB, ROTARY CONTROL

SN: A10001--UP

1шт.

4

22254

CONVERTER, CABLE CONTROL

SN: A10001--UP

1шт.

5

16806

SWITCH, THERMAL CONTROL

SN: A10001--UP

1шт.

6

17461

SWITCH, AIR CONDITIONER/HEATER TOGGLE

SN: A10001--UP

1шт.

7

16656

SWITCH, FAN SPEED CONTROL TOGGLE

SN: A10001--UP

1шт.

8

23280

MOTOR ASSEMBLY, BLOWER

SN: A10001--UP

1шт.

9

NSS

BRACKET

SN: A10001--UP

1шт.

10

17462

FILTER

SN: A10001--UP

1шт.

11

NSS

HOUSING, TOP

SN: A10001--UP

1шт.

12

NSS

BRACKET

SN: A10001--UP

1шт.

13

20667

CORE, HEATER

SN: A10001--UP

1шт.

14

16074

VALVE, EXPANSION

SN: A10001--UP

1шт.

15

20668

EVAPORATOR

SN: A10001--UP

1шт.

16

22256

VALVE, WATER SHUT OFF

SN: A10001--UP

1шт.
