Запчасти Komatsu 450FXL-1 K-A ПЕРЕДН. ОКНАS OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu 450FXL-1 - K-A ПЕРЕДН. ОКНАS OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
1
2
16
2
15
14
2
1
17
19
3
8
10
12
4
5
7
8
9
6
20
21
18
19
20
8
21
20
11
21
12
13

Артикул

Название

Примечание

Количество

1

15507KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

38шт.

2

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

42шт.

3

84803KF

FRAME, OUTER WINDOW (3/4 IN)

SN: A10001--UP

1шт.

|$43

OR

3

-1шт.

3

22262KF

FRAME, OUTER WINDOW (1-1/4 IN)

SN: A10001--UP

1шт.

4

84801KF

WINDOW, MAKROLON FRONT (3/4 IN)

SN: A10001--UP

1шт.

|$44

OR

6

-1шт.

4

22264KF

WINDOW, LEXAN FRONT (1-1/4 IN)

SN: A10001--UP

1шт.

5

84804188KF

MOLDING, CHANNEL WINDOW (3/4 IN)

SN: A10001--UP

-2шт.

|$45

OR

9

-1шт.

5

28968188KF

MOLDING, CHANNEL WINDOW (1-1/4 IN)

SN: A10001--UP

-2шт.

6

84802KF

FRAME, INNER WINDOW (3/4 IN)

SN: A10001--UP

1шт.

|$12

OR

SN: A10001--UP

-1шт.

6

26386KF

FRAME, INNER WINDOW (1-1/4 IN)

SN: A10001--UP

1шт.

7

82685KF

BOLT (WITH 3/4 IN FRAME)

SN: A10001--UP

8шт.

|$46

OR

15

-1шт.

7

4A1-54-10090

BOLT (WITH 1-1/4 IN FRAME)

SN: A10001--UP

8шт.

8

4A1-54-10030

WASHER, FENDER

SN: A10001--UP

16шт.

N/I

4A1-54-10160

SPACER (3/4 IN)

SN: A10001--UP

16шт.

|$47

OR

19

-1шт.

N/I

4A1-54-10040

SPACER (1-1/4 IN)

SN: A10001--UP

16шт.

9

4A1-54-10180

WINDOW, FRONT CAB LIGHTS (3/4 IN)

SN: A10001--UP

1шт.

|$48

OR

22

-1шт.

9

4A1-54-10190

WINDOW, FRONT CAB LIGHTS (1-1/4 IN)

SN: A10001--UP

1шт.

10

4A1-54-10140

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A10001--UP

1шт.

|$49

OR

25

-1шт.

10

4A1-54-10060

WINDOW, L.H. TRACK VIEW (3/4 IN)

SN: A10001--UP

1шт.

11

4A1-54-10150

WINDOW, R.H. TRACK VIEW (3/4 IN)

SN: A10001--UP

1шт.

|$50

OR

28

-1шт.

11

4A1-54-10050

WINDOW, R.H. TRACK VIEW (1-1/4 IN)

SN: A10001--UP

1шт.

12

4A1-54-10210

GASKET, TRACK VIEW WINDOW

SN: A10001--UP

2шт.

13

23604KF

LIGHT, LOWER FRONT WORK

SN: A10001--UP

2шт.

14

12013KF

KNOB, STAR

SN: A10001--UP

4шт.

15

19510KF

BOLT, EYE

SN: A10001--UP

4шт.

16

10731KF

BOLT (0.375 IN x 1-1/2 IN)

SN: A10001--UP

4шт.

17

18126193KF

WEATHERSTRIPPING

SN: A10001--UP

-2шт.

18

4A1-54-10220

GASKET, LOWER FRONT WORK LIGHT WINDOW

SN: A10001--UP

1шт.

19

4A1-54-10090

BOLT (WITH 3/4 IN FRAME)

SN: A10001--UP

8шт.

|$51

OR

38

-1шт.

19

4A1-54-10240

BOLT (WITH 1-1/4 IN FRAME)

SN: A10001--UP

8шт.

N/I

4A1-54-10170

PLATE, LIGHT BACKING

SN: A10001--UP

1шт.

20

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

16шт.

21

15509KF

NUT, NYLOCK (1/4 IN)

SN: A10001--UP

16шт.

Выбрано товаров: 43
