Запчасти Komatsu 450FXL-1 K-A ДВЕРЬ КРЕПЛЕНИЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

4A1-53-10070

SCREW, MACHINE (10 - 24 x 3/8 IN)

SN: A10001--UP

2шт.

2

17897KF

HANDLE, INSIDE DOOR

SN: A10001--UP

1шт.

3

10811KF

NUT, LOCK (1/4 IN)

SN: A10001--UP

4шт.

4

18183KF

STIFFENER, LATCH BOLSTER

SN: A10001--UP

1шт.

5

17895KF

LATCH, DOOR

SN: A10001--UP

1шт.

6

19248KF

HANDLE, OUTSIDE DOOR

SN: A10001--UP

1шт.

7

18273KF

BOLT (1/4 IN x 2-3/4 IN)

SN: A10001--UP

4шт.

8

18126186KF

WEATHERSTRIPPING

SN: A10001--UP

1шт.

9

DOOR ( SEE FIG. K0200-01A0 )

SN: A10001--UP

-1шт.

10

18272KF

SHIM, 1/8 IN DOOR STRIKER

SN: A10001--UP

-2шт.

|$10

18271KF

SHIM, 1/4 IN DOOR STRIKER

SN: A10001--UP

-2шт.

|$11

18390KF

SHIM, 5/16 IN DOOR STRIKER

SN: A10001--UP

-2шт.

11

17896KF

STRIKER, DOOR LATCH

SN: A10001--UP

1шт.

12

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

2шт.

13

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

2шт.

N/I

4A1-54-10340

RIVET, BLIND

SN: A10001--UP

4шт.

N/I

4A1-54-10350

RIVET, BLIND

SN: A10001--UP

18шт.

N/I

16939

KEY, DOOR (CODE CH509)

SN: A10001--UP

1шт.

N/I

18399

KEY, DOOR (CODE CH510)

SN: A10001--UP

1шт.

N/I

16937

KEY, DOOR (CODE CH545)

SN: A10001--UP

1шт.

N/I

16940

KEY, DOOR (CODE CH1250)

SN: A10001--UP

1шт.
