Запчасти Komatsu 450FXL-1 K-A СТАНДАРТН. OPERATORS СИДЕНЬЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

26140KF

SEAT ASSEMBLY, STANDARD OPERATORS

SN: A10001--UP

1шт.

1

22058

COVER

SN: A10001--UP

1шт.

2

22059

PAD KIT, ARM

SN: A10001--UP

1шт.

3

22060

PAD, L.H. ARM REST

SN: A10001--UP

1шт.

4

22062

KNOB, FRONT ARM ADJUSTMENT

SN: A10001--UP

2шт.

5

22063

KNOB, RECLINER

SN: A10001--UP

1шт.

6

22064

CUSHION, SEAT

SN: A10001--UP

1шт.

7

22065

SKIRT, SEAT

SN: A10001--UP

1шт.

8

22066

KNOB, CONTROL CARRIAGE LOCK

SN: A10001--UP

2шт.

9

22051

CARRIAGE, CONTROL

SN: A10001--UP

1шт.

10

22067

SPRING, GAS

SN: A10001--UP

2шт.

11

19254

BRACKET, JOYSTICK MOUNTING

SN: A10001--UP

2шт.

12

22068

SCREW, MACHINE (1/4 IN - 5/8 IN)

SN: A10001--UP

8шт.

13

22069

NUT, SPEED (1/4 IN)

SN: A10001--UP

8шт.

14

22070

KNOB, LUMBAR SUPPORT ADJUSTMENT

SN: A10001--UP

1шт.

15

22061

PAD, R.H. ARM REST

SN: A10001--UP

1шт.

N/I

22071

SKIRT, L.H. JOYSTICK MOUNT

SN: A10001--UP

1шт.

N/I

22072

SKIRT, R.H. JOYSTICK MOUNT

SN: A10001--UP

1шт.
