Запчасти Komatsu 450FXL-1 H-A ГИДРОЛИНИЯ ВСПОМОГ. МАСЛООХЛАДИТЕЛЬ ЛИНИЯ ГИДРАВЛИКА

1

22944KF

ELBOW

SN: A10001--UP

1шт.

2

11306KF

ELBOW, 90 DEGREE (6801-12-12)

SN: A10001--UP

1шт.

3

15191KF

CLAMP, STRAP BAND (1-1/2 IN)

SN: A10001--UP

2шт.

4

28535KF

HOSE ASSEMBLY (2113-12-12JS-12J4-W)

SN: A10001--UP

1шт.

5

28455KF

HOSE ASSEMBLY (2024-16-0-0-W)

SN: A10001--UP

1шт.

6

4A1-62-10240

CONNECTOR (0188-16-16)

SN: A10001--UP

1шт.

7

27993KF

VALVE, BALL (1 IN)

SN: A10001--UP

1шт.

8

16374KF

ELBOW, 45 DEGREE STREET (FORGED ONLY)

SN: A10001--UP

1шт.

9

15478KF

ELBOW

SN: A10001--UP

1шт.

10

28177KF

SWIVEL, HYDRAULIC (16MJIC-16FJIC)

SN: A10001--UP

1шт.

11

15351KF

CONNECTOR

SN: A10001--UP

1шт.

12

NSS

O-RING

SN: A10001--UP

1шт.

13

15326KF

FILTER, MESH SUCTION

SN: A10001--UP

1шт.

14

16760KF

BUSHING (2 IN x 1 IN)

SN: A10001--UP

1шт.

15

PUMP, HYDRAULIC DRIVEN OIL COOLER ( SEE FIG. H0242-01A0 )

SN: A10001--UP

-1шт.

16

22618KF

NIPPLE, KING

SN: A10001--UP

1шт.
