Запчасти Komatsu 450FXL-1 H-A ВСПОМОГ. МАСЛООХЛАДИТЕЛЬ КРЕПЛЕНИЕ ГИДРАВЛИКА

1

COOLER, AUXILIARY OIL ( SEE FIG. H0325- 02A0 )

SN: A10001--UP

-1шт.

2

VALVE, PROPORTIONAL RELIEF ( SEE FIG. H0325-02A0 )

SN: A10001--UP

-1шт.

3

17651KF

BUSHING, REDUCER (6410-20-12)

SN: A10001--UP

2шт.

4

11306KF

ELBOW, 90 DEGREE (6801-12-12)

SN: A10001--UP

2шт.

5

15472KF

ELBOW, 45 DEGREE SWIVEL (6502-12)

SN: A10001--UP

1шт.

6

81703KF

FITTING (12 R50X-S)

SN: A10001--UP

1шт.

7

81850KF

ELBOW

SN: A10001--UP

1шт.

8

20991KF

CONNECTOR, STRAIGHT LONG (848L-TT0- 04X04)

SN: A10001--UP

1шт.

9

15477KF

ELBOW, 90 DEGREE (12Z0EG5-5)

SN: A10001--UP

1шт.

10

00830055

CONNECTOR

SN: A10001--UP

1шт.

11

11324KF

FITTING (6400-12)

SN: A10001--UP

1шт.

12

81594KF

HOSE ASSEMBLY (2042-12-12JS-12J9-W)

SN: A10001--UP

1шт.

13

28456KF

HOSE ASSEMBLY (2021-16-160S-16J9)

SN: A10001--UP

1шт.

14

28454KF

HOSE ASSEMBLY (2022-12-12JS-12J9)

SN: A10001--UP

1шт.

15

81771KF

HOSE ASSEMBLY (2023-06-060S-0409)

SN: A10001--UP

1шт.

16

81676KF

HOSE ASSEMBLY (2028-12-12JS-12J9)

SN: A10001--UP

1шт.

17

81595KF

HOSE ASSEMBLY (2020-12-12JS-12JS)

SN: A10001--UP

1шт.

18

17009KF

C0NNECTOR, STRAIGHT BULKHEAD (2700-12)

SN: A10001--UP

2шт.

19

18782KF

SWIVEL, INLINE STR (LS2406-1212)

SN: A10001--UP

2шт.

20

15472KF

ELBOW, 45 DEGREE SWIVEL (6502-12)

SN: A10001--UP

2шт.

21

15351KF

CONNECTOR, STRAIGHT BULKHEAD (2041-16- 16S)

SN: A10001--UP

1шт.

22

28177KF

SWIVEL, HYDRAULIC (16MJIC-16FJIC)

SN: A10001--UP

1шт.

23

15478KF

ELBOW, 90 DEGREE SWIVEL (6500-16)

SN: A10001--UP

1шт.

24

11707KF

BOLT

SN: A10001--UP

4шт.

25

15528KF

WASHER

SN: A10001--UP

8шт.

26

10813KF

NUT

SN: A10001--UP

4шт.

27

26665KF

GROMMET

SN: A10001--UP

1шт.
