Запчасти Komatsu 450FXL-1 H-A IMPLEMENT НАСОС ГИДРАВЛИКА

|$0

81819KF

PUMP, IMPLEMENT

SN: A10001--UP

1шт.

1

NSS

HOUSING, IMPLEMENT PUMP

SN: A10001--UP

1шт.

2

21546

RING, SEAL RETAINING

SN: A10001--UP

1шт.

3

21547

COVER, FRONT

SN: A10001--UP

1шт.

4

21548

O-RING, FRONT COVER

SN: A10001--UP

1шт.

5

18687KF

SEAL, SHAFT

SN: A10001--UP

1шт.

6

18681

COMPENSATOR

SN: A10001--UP

1шт.

7

20809

O-RING, QUAD

SN: A10001--UP

3шт.

8

20808

O-RING, COMPENSATOR

SN: A10001--UP

1шт.

9

NSS

SPOOL, POR PRESSURE

SN: A10001--UP

1шт.

10

21551

RETAINER, SPRING

SN: A10001--UP

2шт.

11

21552

SPRING

SN: A10001--UP

1шт.

12

21553

O-RING, COMPENSATOR CAP

SN: A10001--UP

2шт.

13

21554

CAP, COMPENSATOR

SN: A10001--UP

2шт.

14

4899889

NUT, SEAL

SN: A10001--UP

2шт.

15

21555

SCREW, ADJUSTING

SN: A10001--UP

2шт.

16

21558

RETAINER, SPRING

SN: A10001--UP

2шт.

17

21556KF

SPRING

SN: A10001--UP

1шт.

18

21557

SPRING

SN: A10001--UP

1шт.

19

NSS

SLEEVE, SPOOL

SN: A10001--UP

1шт.

20

NSS

SPOOL, STAND BY PRESSURE

SN: A10001--UP

1шт.

21

21559

BOLT

SN: A10001--UP

5шт.

22

NSS

PLUG

SN: A10001--UP

1шт.

23

27210

FLANGE, THRU DRIVE

SN: A10001--UP

1шт.

24

27214KF

BOLT

SN: A10001--UP

4шт.

25

27212

O-RING

SN: A10001--UP

1шт.

|$26

24423KF

THRU DRIVE KIT FOR 45CC AUXILIARY PUMP

-1шт.

26

18843

COUPLING, THRU DRIVE

SN: A10001--UP

1шт.

27

27219KF

SCREW (12 MM x 1.75 x 30 MM)

SN: A10001--UP

4шт.

28

27215

FLANGE

SN: A10001--UP

1шт.

29

27217KF

O-RING

SN: A10001--UP

1шт.

30

27218KF

O-RING

SN: A10001--UP

1шт.

|$32

24905KF

THRU DRIVE KIT FOR 71CC AUXILIARY PUMP

-1шт.

26

NSS

COUPLING, THRU DRIVE

SN: A10001--UP

1шт.

27

27214KF

SCREW

SN: A10001--UP

4шт.

28

NSS

FLANGE

SN: A10001--UP

1шт.

29

27212

O-RING

SN: A10001--UP

1шт.

30

27213

O-RING

SN: A10001--UP

1шт.

|$38

18799

REPAIR KIT, SEAL

SN: A10001--UP

1шт.

|$39

39

-1шт.

|$40

F1 - PART INCLUDED IN COMPLETE PUMP SEAL KIT:

40

-1шт.
