Запчасти Komatsu 450FXL-1 H-A ПОДКАЧИВАЮЩ. НАСОС ВСАСЫВ. ЛИНИЯ ГИДРАВЛИКА

1

15842KF

FILTER, SCREEN

SN: A10001--UP

1шт.

2

15448KF

O-RING (5-1/2 IN OD)

SN: A10001--UP

1шт.

3

22462KF

PLATE, INTERMEDIATE SUCTION PORT

SN: A10001--UP

1шт.

4

22441KF

VALVE, SHUT OFF BUTTERFLY

SN: A10001--UP

1шт.

5

15641KF

CLAMP, STRAP BAND (2 IN)

SN: A10001--UP

2шт.

6

28461KF

HOSE ASSEMBLY (2021-24-0-0)

SN: A10001--UP

1шт.

7

19824KF

COUPLING, KING

SN: A10001--UP

1шт.

8

PUMP, CHARGE ( SEE FIG. H0242-01A0 )

SN: A10001--UP

-1шт.

9

23095KF

BOLT (5/8 IN x 2 IN)

SN: A10001--UP

4шт.

|$9

22639KF

FLANGE ASSEMBLY

SN: A10001--UP

1шт.

10

NSS

FLANGE

SN: A10001--UP

1шт.

11

18695KF

O-RING

SN: A10001--UP

2шт.

12

NSS

BOLT (M16 x 45 MM)

SN: A10001--UP

4шт.

13

NSS

WASHER (M16)

SN: A10001--UP

4шт.

14

27541KF

TUBE, SUCTION (2 IN)

SN: A10001--UP

1шт.

15

27668KF

PLUG (6408-32)

SN: A10001--UP

1шт.
