Запчасти Komatsu 445FXL-1 H-7A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ИНСТРУМЕНТ НАКЛОН. SECTION ГИДРАВЛИКА

|$0

VALVE, MAIN CONTROL ( SEE FIG. H0120-02A0 OR SEE FIG. H0120-03A0 )

SN: A10001--UP

-1шт.

|$1

24648

VALVE ASSEMBLY, TOOL TILT SECTION

SN: A10001--UP

1шт.

1

NSS

BODY

SN: A10001--UP

1шт.

2

NSS

PLUG

SN: A10001--UP

1шт.

|$4

26421

PLUG ASSEMBLY, (0.8 MM ORIFICE)

SN: A10001--UP

1шт.

3

NSS

PLUG

SN: A10001--UP

1шт.

4

NSS

RING, BACK-UP

SN: A10001--UP

1шт.

5

NSS

O-RING

SN: A10001--UP

1шт.

|$8

26415

COMPENSATOR, K2 (BLUE)

SN: A10001--UP

1шт.

6

NSS

GUIDE, SPRING

SN: A10001--UP

1шт.

7

NSS

SPRING, COMPENSATOR

SN: A10001--UP

1шт.

8

NSS

SPRING, COMPENSATOR

SN: A10001--UP

1шт.

9

NSS

WASHER, SMALL

SN: A10001--UP

1шт.

10

NSS

WASHER, LARGE

SN: A10001--UP

1шт.

11

NSS

SPOOL, COMPENSATOR (BLUE)

SN: A10001--UP

1шт.

12

26428

SPRING KIT, PC

SN: A10001--UP

1шт.

13

NSS

SPOOL ORIFICE, PLUG

SN: A10001--UP

1шт.

14

26430

SPOOL, YRX

SN: A10001--UP

1шт.

15

NSS

SPOOL ORIFICE, PLUG

SN: A10001--UP

1шт.

16

26551

WASHER, SEAL

SN: A10001--UP

1шт.

17

26550

BOLT, SPOOL

SN: A10001--UP

1шт.

|$21

26422

PLUG KIT

SN: A10001--UP

1шт.

18

NSS

PLUG

SN: A10001--UP

1шт.

19

NSS

O-RING

SN: A10001--UP

2шт.

20

NSS

RING, BACK-UP

SN: A10001--UP

2шт.

21

END CAP SECTION, A-SIDE ( SEE FIG. H0120-20A0 )

SN: A10001--UP

-1шт.

22

26418

SEAL KIT, EC A-SIDE

SN: A10001--UP

1шт.

|$27

NSS

VALVE KIT, PORT RELIEF

SN: A10001--UP

2шт.

23

NSS

COVER

SN: A10001--UP

1шт.

24

NSS

SPRING, PORT RELIEF

SN: A10001--UP

2шт.

25

NSS

VALVE, PORT RELIEF

SN: A10001--UP

2шт.

|$31

26426KF

PLUG KIT, PORT RELIEF

SN: A10001--UP

2шт.

26

NSS

PLUG

SN: A10001--UP

2шт.

27

NSS

O-RING

SN: A10001--UP

2шт.

|$34

26416

REDUCER, FEED

SN: A10001--UP

2шт.

28

NSS

COVER

SN: A10001--UP

1шт.

29

NSS

SCREW, ADJUSTMENT

SN: A10001--UP

1шт.

30

NSS

NUT

SN: A10001--UP

1шт.

31

NSS

SPOOL

SN: A10001--UP

1шт.

32

NSS

O-RING

SN: A10001--UP

1шт.

33

NSS

O-RING

SN: A10001--UP

1шт.

34

END CAP SECTION, B-SIDE ( SEE FIG. H0120-20A0 )

SN: A10001--UP

-1шт.

35

SEAL KIT, PC B-SIDE ( SEE FIG. H0120- 20A0 )

SN: A10001--UP

-1шт.
