Запчасти Komatsu 445FXL-1 H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН (V/ SECTION) КЛАПАН СЕКЦ. ГИДРАВЛИКА

|$0

84921KF

VALVE ASSEMBLY, MAIN CONTROL

SN: A10001--UP

1шт.

1

VALVE, MAIN INLET PRESSURE AND RETURN ( SEE FIG. H0120-04A0 )

SN: A10001--UP

-1шт.

2

VALVE, SAW/SHEAR FUNCTION ( SEE FIG. H0120-05A0 )

SN: A10001--UP

-1шт.

3

VALVE, CLAMP FUNCTION ( SEE FIG. H0120- 06A0 )

SN: A10001--UP

-1шт.

4

VALVE, TOOL TILT FUNCTION ( SEE FIG. H0120-07A0 )

SN: A10001--UP

-1шт.

5

VALVE, STICK BOOM FUNCTION ( SEE FIG. H0120-08A0 )

SN: A10001--UP

-1шт.

6

VALVE, MAIN BOOM ( SEE FIG. H0120-09A0 )

SN: A10001--UP

-1шт.

7

85943

MID ADAPTER, SINGLE PUMP

SN: A10001--UP

1шт.

8

VALVE, SWING ( SEE FIG. H0120-10A0 )

SN: A10001--UP

-1шт.

9

VALVE, L90 ( SEE FIG. H0120-11A0 )

SN: A10001--UP

-1шт.

10

VALVE, ACCUMULATOR, LATERAL TILT, CLAMP FUNCTION ( SEE FIG. H0120-12A0 )

SN: A10001--UP

-1шт.

11

VALVE, CAB LEVELER ( SEE FIG. H0120- 13A0 )

SN: A10001--UP

-1шт.

12

26405

VALVE, INLET PLATE

SN: A10001--UP

1шт.

13

955784

NUT

SN: A10001--UP

3шт.

14

24649

REPAIR KIT, SEAL

SN: A10001--UP

6шт.

15

28715KF

ROD, TIE

SN: A10001--UP

3шт.

16

5030371

REPAIR KIT, L90LS FACE SEALS

SN: A10001--UP

5шт.

17

26139

ROD, TIE

SN: A10001--UP

3шт.

18

15530KF

NUT

SN: A10001--UP

3шт.

19

15528KF

WASHER

SN: A10001--UP

3шт.
