Запчасти Komatsu 445FXL-1 H-A ОСНОВН. КРЕПЛЕНИЕ КОНТРОЛЬНОГО КЛАПАНА ГИДРАВЛИКА

1

VALVE ASSEMBLY, MAIN CONTROL ( SEE FIG. H0120-02A0 )

SN: A10001--UP

-1шт.

2

10739KF

BOLT (1 IN x 1-1/2 IN)

SN: A10001--UP

6шт.

3

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

8шт.

4

10804KF

WASHER, FLAT (1/2 IN)

SN: A10001--UP

8шт.

5

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

6шт.

6

10723KF

BOLT (4-1/2 IN x 5/8 IN)

SN: A10001--UP

2шт.

7

15525KF

ISOLATOR, ENGINE MOUNT

SN: A10001--UP

2шт.

8

14570KF

BRACKET, MAIN CONTROL VALVE MOUNTING

SN: A10001--UP

1шт.

9

15524KF

WASHER, ISOLATOR MOUNT

SN: A10001--UP

2шт.

10

10816KF

NUT, LOCK (0.625 IN)

SN: A10001--UP

2шт.

11

18295KF

BOLT, ALLEN HEAD (1/2 IN)

SN: A10001--UP

2шт.

12

14583KF

BRACKET, VALVE MOUNT

SN: A10001--UP

1шт.
