Запчасти Komatsu 445FXL-1 H-A ГИДР. БАК. КРЕПЛЕНИЕ ГИДРАВЛИКА

1

TANK, HYDRAULIC ( SEE FIG. H0110-01A0 )

SN: A10001--UP

-1шт.

2

23598KF

GUARD, RETURN FILTER

SN: A10001--UP

1шт.

3

15565KF

BOLT (1 IN x 2-1/2 IN)

SN: A10001--UP

5шт.

4

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

12шт.

5

10815KF

NUT, LOCK (1/2 IN)

SN: A10001--UP

7шт.

6

26868KF

SUPPORT, HYDRAULIC TANK

SN: A10001--UP

1шт.

7

27399KF

PLATE, FILTER GUARD COVER

SN: A10001--UP

1шт.

8

10757KF

WASHER, SAE FLAT (1/4 IN)

SN: A10001--UP

4шт.

9

10736KF

BOLT (1/2 IN x 2 IN)

SN: A10001--UP

2шт.

10

15502KF

BOLT (5/8 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

11

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

2шт.

12

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

9шт.

13

15542KF

BOLT (3/8 IN x 3/4 IN)

SN: A10001--UP

9шт.

14

19771KF

LATCH, CAM

SN: A10001--UP

2шт.

15

15604KF

BOLT (1/4 IN x 3/4 IN)

SN: A10001--UP

4шт.

16

27825KF

COVER, HYDRAULIC TANK DEBRIS

SN: A10001--UP

1шт.
