Запчасти Komatsu 445FXL-1 H-A ГИДР. БАК. ГИДРАВЛИКА

1

26292KF

TANK, HYDRAULIC OIL

SN: A10001--UP

1шт.

2

10783KF

BOLT (1/2 IN x 1 IN)

SN: A10001--UP

8шт.

3

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

8шт.

4

18635

COVER, TANK ACCESS

SN: A10001--UP

1шт.

5

15600KF

O-RING (8 IN DIA)

SN: A10001--UP

1шт.

6

15448KF

O-RING, HYDRAULIC TANK COVER (5-1/2 IN DIA)

SN: A10001--UP

1шт.

7

22462KF

COVER, SUCTION PORT

SN: A10001--UP

1шт.

8

16852

REPAIR KIT, SEAL

SN: A10001--UP

3шт.

9

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

12шт.

10

10402KF

BOLT (3/8 IN x 1-1/4 IN)

SN: A10001--UP

12шт.

11

22888KF

BOLT (1/2 IN x 2-3/4 IN)

SN: A10001--UP

8шт.

12

15534KF

WASHER, SAE FLAT (1/2 IN)

SN: A10001--UP

8шт.

13

22634KF

MANIFOLD, CASE DRAIN

SN: A10001--UP

2шт.

14

15389KF

O-RING (1-1/2 IN SF - CODE 61/62)

SN: A10001--UP

2шт.

15

FILTER, CASE DRAIN RETURN ( SEE FIG. H0111-01A0 )

SN: A10001--UP

-1шт.

16

FILTER, ATTACHMENT RETURN ( SEE FIG. H0111-01A0 )

SN: A10001--UP

-1шт.

17

22618KF

COUPLING

SN: A10001--UP

2шт.

18

19578KF

CLAMP

SN: A10001--UP

2шт.

19

18107KF

HOSE, FILTER CONNECTION

SN: A10001--UP

1шт.

20

FILTER, OIL COOLER RETURN ( SEE FIG. H0112-01A0 )

SN: A10001--UP

-1шт.

21

23016KF

PLUG (6408-HHP-24)

SN: A10001--UP

1шт.

22

16774KF

PLUG (3 IN)

SN: A10001--UP

3шт.

23

11384KF

PLUG (6408-8)

SN: A10001--UP

2шт.

24

15584KF

PLUG (6408-HHP-12)

SN: A10001--UP

1шт.
