Запчасти Komatsu 445FXL-1 E-A ЭЛЕКТРОНН. ПОВОРОТН. СТОП КОРПУС ЭЛЕКТРИКА

|$0

19159KF

BOX ASSEMBLY, ELECTRONIC SWING STOP

SN: A10001--UP

1шт.

1

15688

HOUSING

SN: A10001--UP

1шт.

2

15687

SCREW, LEAD

SN: A10001--UP

1шт.

3

15588

PIN, ROLL (3/16 IN x 1-1/2 IN)

SN: A10001--UP

2шт.

4

10731KF

BOLT (0.375 IN x 1-1/2 IN)

SN: A10001--UP

4шт.

5

15846

BEARING, LEAD SCREW

SN: A10001--UP

2шт.

6

15507KF

NUT, NYLOCK (0.375 IN)

SN: A10001--UP

6шт.

7

NSS

ACTUATOR

SN: A10001--UP

1шт.

8

15605KF

BOLT (5/16 IN x 3/4 IN)

SN: A10001--UP

2шт.

9

00230101

WASHER, LOCK

SN: A10001--UP

2шт.

10

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

2шт.

11

15920

COVER

SN: A10001--UP

1шт.

12

23511

PLATE, SWITCH BACKING

SN: A10001--UP

2шт.

13

16127KF

SCREW, MACHINE (10 - 24 x 1-1/4 IN)

SN: A10001--UP

2шт.

14

24642KF

SWITCH, LIMIT SWING STOP

SN: A10001--UP

2шт.

15

16129KF

BOLT (3/8 IN x 2-1/2 IN)

SN: A10001--UP

2шт.

16

19171

STRIP, TERMINAL 6 POSITION

SN: A10001--UP

1шт.
