Запчасти Komatsu 445FXL-1 D-A NON-CONTINUOUS ROTATION ТОПЛИВН. СИСТЕМА ТОПЛИВНАЯ ЛИНИЯ ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

16009

CONNECTOR

SN: A10001--UP

2шт.

2

28537KF

HOSE (2172-08-08PS-08J9)

SN: A10001--UP

1шт.

3

16619KF

HOSE ASSEMBLY (2144-04-04PS-0)

SN: A10001--UP

1шт.

4

84562KF

HOSE ASSEMBLY (2013-08-08JS-08J9)

SN: A10001--UP

1шт.

5

22619KF

HOSE ASSEMBLY (2180-08-08PS-08J9)

SN: A10001--UP

1шт.

6

15556KF

BOLT (12 MM - 1.75P x 20 MM)

SN: A10001--UP

1шт.

7

18735KF

WASHER, FLAT (12 MM)

SN: A10001--UP

1шт.

8

ROTARY VANE FUEL PUMP ( SEE FIG. D0200- 05A1 )

SN: A10001--UP

-1шт.

9

11355KF

ELBOW, 90 DEGREE SWIVEL (6901-8-8)

SN: A10001--UP

2шт.

10

18063KF

ELBOW, 90 DEGREE SWIVEL (6901-8-4)

SN: A10001--UP

1шт.

11

16010KF

CONNECTOR, STR (2404-08-6)

SN: A10001--UP

1шт.

12

24376KF

ELBOW, 90 DEGREE (2501-8-6)

SN: A10001--UP

1шт.

13

23491KF

SLEEVE, HOSE WRAP (225 X 112 IN)

SN: A10001--UP

1шт.

N/I

08034-20823

BAND, TIE

SN: A10001--UP

4шт.
