Запчасти Komatsu 445FXL-1 V-A FIRE SUPPRESSION СИСТЕМА РУЧН. АКТУАТОР ТРУБЫ АКСЕССУАРЫ

1

ACTUATOR, PNEUMATIC ( SEE FIG. V0100- 03A0 )

SN: A10001--UP

-1шт.

2

10320KF

ELBOW, 90 DEGREE SWIVEL (1501-4-4)

SN: A10001--UP

2шт.

3

15567KF

CONNECTOR, STRAIGHT (5404-4)

SN: A10001--UP

2шт.

4

16778KF

VALVE

SN: A10001--UP

2шт.

5

17769

HOSE ASSEMBLY

SN: A10001--UP

1шт.

6

15589KF

BOLT (5/16 IN x 1 IN)

SN: A10001--UP

2шт.

7

15606KF

WASHER, LOCK (5/16 IN)

SN: A10001--UP

2шт.

8

15559KF

WASHER, SAE FLAT (5/16 IN)

SN: A10001--UP

2шт.

9

21147KF

WASHER

SN: A10001--UP

1шт.

10

16750KF

HOSE ASSEMBLY

SN: A10001--UP

1шт.

11

ACTUATOR, INTERIOR ( SEE FIG. V0100-05A0 )

SN: A10001--UP

-1шт.

12

15529KF

BOLT (3/8 IN x 2 IN)

SN: A10001--UP

2шт.

13

15528KF

WASHER, SAE FLAT (3/8 IN)

SN: A10001--UP

4шт.

14

10813KF

NUT, LOCK (3/8 IN)

SN: A10001--UP

2шт.

15

ACTUATOR, EXTERIOR ( SEE FIG. V0100-04A0 )

SN: A10001--UP

-1шт.

16

11372KF

ELBOW

SN: A10001--UP

1шт.

17

21299

VALVE, SAFETY RELIEF

SN: A10001--UP

1шт.

18

85847

TEE

SN: A10001--UP

1шт.

19

85846

PIPE, NIPPLE

SN: A10001--UP

1шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS AVAILABLE FROM AUTHORIZED ANSUL DISTRIBUTORS ONLY.

20

-1шт.
