Запчасти Komatsu 445FXL-1 T-A РАБОЧЕЕ ОБОРУДОВАНИЕ ТРУБКА ЛИНИИ DROOP NOSE РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

1

80917KF

TUBE (BENT 1 IN x 92 IN)

SN: A10001--UP

2шт.

2

80918KF

TUBE (BENT 1 IN x 94 IN)

SN: A10001--UP

3шт.

3

80919KF

TUBE (BENT 1/2 IN x 97 IN)

SN: A10001--UP

2шт.

4

80922KF

TUBE, ELECTRICAL CONDUIT (1 IN)

SN: A10001--UP

1шт.

5

26513KF

COVER, ELECTRICAL WIRE TUBE

SN: A10001--UP

1шт.

6

15272KF

CLAMP, SADDLE TOP TUBE (1/2 IN x 1/2 IN)

SN: A10001--UP

2шт.

7

26904KF

CLAMP, SADDLE (1 IN x 1 IN x 1 IN)

SN: A10001--UP

4шт.

8

85095KF

SPACER, BASE (3-1/2 IN x 3 IN)

SN: A10001--UP

1шт.

9

26981

BOLT (5/8 IN x 6-1/2 IN)

SN: A10001--UP

4шт.

10

10723KF

BOLT (5/8 IN x 4-1/2 IN)

SN: A10001--UP

2шт.

11

10771KF

WASHER, SAE FLAT (5/8 IN PL GR9)

SN: A10001--UP

6шт.

12

18564KF

BUSHING (3-1/2 IN x 4-1/4 IN)

SN: A10001--UP

2шт.

13

80961KF

GUARD, PLATE

SN: A10001--UP

1шт.

14

15549KF

BOLT (3/4 IN x 2 IN)

SN: A10001--UP

1шт.

15

15550KF

WASHER, SAE FLAT (3/4 IN)

SN: A10001--UP

1шт.

16

26904KF

CLAMP, SADDLE

SN: A10001--UP

2шт.
