Запчасти Komatsu 445FXL-1 D-A CONTINUOUS ROTATION ТОПЛИВН. СИСТЕМА ПОВОРОТН. КОЛЛЕКТОР - ПОВОРОТН. VANE ТОПЛИВН. НАСОС ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

4A1-62-10530

ELBOW, 90 DEGREE SWIVEL (10-L0EX6-S)

SN: A10001--UP

1шт.

2

4A1-62-10540

CONNECTOR, STRAIGHT (10-6FTX-6)

SN: A10001--UP

1шт.

3

BRACKET, FUEL PUMP MOUNTING ( SEE FIG. D0200-05A0 )

SN: A10001--UP

-1шт.

4

24115KF

HOSE ASSEMBLY (2060-08-080S-0809)

SN: A10001--UP

1шт.

|$9

OR

4

-1шт.

4

4A1-06-10920

HOSE ASSEMBLY (HF210-60-1-JSKY-10-10/ 1J9HY-10)

SN: A10001--UP

1шт.

5

15117KF

CONNECTOR (FF1852T-0808S)

SN: A10001--UP

1шт.

|$10

OR

7

-1шт.

5

206-62-U1370

CONNECTOR, STRAIGHT (10-8-F50L0-S)

SN: A10001--UP

1шт.

|$11

9

-1шт.

|$12

F1 - WHEN REPLACING ROTARY MANIFOLD P/N 26400KF, HOSE P/N 24115KF MUST BE REPLACED BY HOSE P/N 4A1-06-10920, CON NECTOR P/N 15117KF MUST BE REPLACED BY CONNECTOR P/N 206-62-U1370. IN ADDITION ORDER CONNECTOR P/N 4A1-62-0520 AND ELBOW P

10

-1шт.
